- Page 1 User and maintenance instructions Air operated grease pump Model 83167, series “J” Date of issue November 2017 Form number 404402 Version...
- Page 2 Contents Safety Explanation of signal words for safety Read and carefully observe operating instructions before unpacking and operating pump Pump must be operated, maintained Safety and repaired exclusively by persons familiar NOTE Explanation of safety signals with operating instructions Local safety Emphasizes useful hints and Description regulations regarding installation, operation...
- Page 3 Specifications Lubricant output Reservoir Air Lubricant Lubricant operating pressure Ratio Per cycle Per minute at 100 psi (60 bar) capacity inlet outlet Type of system Minimum Maximum Recommended 40:1 0 11 in 12 in (197 cm 12 lbs SL-1 1 850 psi 3 550 psi 2 500 psi (172 bar) (1,8 cm...
- Page 4 Fig. 1 Dimensions / in / in / in / in / in NPTF / in NPTF / in NPTF / in NPTF / in NPTF Vent valve (38)
- Page 5 Lubricate air valve Prime system Vent valve mechanism Vent valve (38) operates with compressed air Supply lines from same source that operates pump Disconnect air to pump and remove Operate pump until lubricant starts to bleed When pump is in operation, air pressure four cover screws (61), cover plate (96) around vent plug to expel air pockets keeps vent valve closed and lubricant is...
- Page 6 Fig. IPB 2 Model 84509 / in NPTF Air exhaust port Torque 30 to 40 in lbf (3,3 to 4,5 Nm) Torque 90 to 100 in lbf (10 to 12 Nm) Assemble with Loctite #242 Blue Tighten to 20 to 25 ft lbf (27 to 33 Nm)
- Page 7 Fig. 2 Model 84509 / in NPTF Tighten to 10 to 15 ft lbf (13,5 to 20,3 Nm) Torque to 95 to 105 ft lbf (128 to 142 Nm)
- Page 8 Service parts Item Description Qty Part no Item Description Part no Item Description Part no Gasket (nitrile) 34308 90° tube connector 256101* Steel ball 66002 Retaining ring 274225 Vent valve assembly 83948 Check housing 12093 Lockwasher 66246 Support adapter 16471 Outlet body 12095 Screw...
- Page 9 Troubleshooting Problem Cause Solution Pump operates continuously Pump has lost prime Examine lubricant supply Refill reservoir if necessary Air pocket trapped in lubricant Loosen vent plug one turn Allow pump to operate until trapped air is pumped out Close vent plug Pump continues to operate without discharging Pump check (71) and steel ball (73) Remove and clean checks and check seats...
- Page 10 This page left intentionally blank...
- Page 11 This page left intentionally blank...
- Page 12 | lincolnindustrial.com ® SKF and Lincoln are registered trademarks of the SKF Group © SKF Group 2017 The contents of this publication are the copyright of the publisher and may not be reproduced (even...
