User manual
Ultra high-pressure
PowerMaster III pump tube
Models 85304 and 85305, series A
Date of issue
March 2025
Form number
403352
Version
4

Advertisement

loading
Need help?

Need help?

Do you have a question about the LINCOLN PowerMaster III and is the answer not in the manual?

Questions and answers

Summary of Contents for SKF LINCOLN PowerMaster III

  • Page 1 User manual Ultra high-pressure PowerMaster III pump tube Models 85304 and 85305, series A Date of issue March 2025 Form number 403352 Version...
  • Page 2: Table Of Contents

    Contents Declaration of Incorporation * ..........U.K.
  • Page 3: Declaration Of Incorporation

    Manufacturer name/address: Lincoln Industrial Corporation 5148 N. Hanley Road St. Louis, MO 63134 U.S.A. TEL: +1 (314) 679-4200 FAX: +1 (314) 679-4367 Authorized to compile the technical file: SKF Lubrication Systems Germany GmbH Heinrich-Hertz-Straße 2-8 69190 Walldorf, Germany EMAIL: robert.collins@skf.com WEBSITE: www.skf.com...
  • Page 4: U.k. Declaration Of Incorporation

    Lincoln Industrial Corporation 5148 N. Hanley Road St. Louis, MO 63134 U.S.A. TEL: +1 (314) 679-4200 FAX: +1 (314) 679-4367 Authorized to compile the technical file: SKF (U.K.) Limited 2 Canada Close Banbury, Oxfordshire, OX16 2RT, GBR EMAIL: WEBSITE: robert.collins@skf.com www.skf.com...
  • Page 5: Safety

    CAUTION  death or serious personal injury. Do not disassemble pump unless you are a qualified CAUTION technician. Contact SKF  Indicates a dangerous situation that WARNING service center for more information.  can lead to light personal injury if...
  • Page 6: Overview

    Overview Table 1 Product specification Ultra high-pressure pump tubes are designed specifically for oil well services Pump stroke 6 in. (152 mm) Output per cycle 2 in. (33 cm such as wire line and plug valve Maximum delivery pressure 20 000 psi (1 380 bar) applications.
  • Page 7: Model Chart

    Table 2 Model chart Pump tube Pump model Air motor Ratio Maximum delivery pressure Maximum air pressure 85304 2390 84808 250:1 20 000 psi (1 380 bar) 80 psi (5,5 bar) 2392 84806 140:1 14 000 psi (965 bar) 100 psi (6,9 bar) 2394 84804 70:1...
  • Page 8: Performance Chart: Models 2394 And 2395 (70:1 Ratio)

    Fig. 4 Performance chart: models 2394 and 2395 (70:1 ratio) Delivery pressure (psi (bar)) Air consumption (scfm (m /min)) 8 000 100 psi (552) (2,3) (6,89 bar) 7 000 (483) 100 psi (6,89 bar) 6 000 70 psi (1,7) (413) (4,82 bar) 5 000 (345)
  • Page 9: Disassembly

    Disassembly Fig. 6 Outlet housing Outlet housing 1 Unscrew bolt connector (10) and coupling nut (9) assembly from plunger rod (5) (→ Fig. 6). 2 Unscrew bushing nut (8) from outlet body (11). 3 Remove v-packing set (7) from bushing nut (8). 4 Remove six wave washers (6), two flat washers (12) and O-ring (13) from outlet body (11).
  • Page 10: Pump Tube Disassembly

    Pump tube disassembly Fig. 8 Pump tube In most cases, pump tube repair involves priming check and plunger (17), bushing and plunger (1) or plunger rod (5). Repair procedure in part requires removing adapter tube (23) and priming tube adapter (22) from pump tube (25). In these cases, leave pump tube (25) attached to outlet body (11).
  • Page 11: Outlet Body And Plunger

    Outlet body and plunger Fig. 9 Plunger rod 1 Unscrew plunger rod (5) from plunger (connecting) rod assembly (26) (→ Fig. 9 and Fig. IPB 1, page 13). 2 Unscrew plunger (connecting) rod assembly (26) from bushing and plunger (1). 3 Remove check ball (2), pin (3) and check ball (4) from bushing and plunger (1).
  • Page 12: Troubleshooting

    Table 3 Troubleshooting Problem Possible cause Solution Pump does not operate. 1 Restricted or inadequate air supply. 1 Check air supply pressure and air hose diameter (refer to air motor manual for minimum air supply hose diameter). 2 Obstructed material output. 2 Check output line for restrictions.
  • Page 13: Pump Tube - Exploded View

    Fig. IPB 1 Pump tube - Exploded view 28 * 27 * Indicates change.
  • Page 14: Pump Tube - Section View

    Fig. IPB 2 Pump tube - Section view 6 (x 2) 6 (x 2) 6 (x 2) 28 * 27 * Torque to 1 000 to 1 100 ft.lbf (1 356 to 1 491 Nm). Torque to 250 to 275 ft.lbf. (339 to 373 Nm). Torque to 20 to 22 ft.lbf.
  • Page 15: Warranty

    ® SKF and Lincoln are registered trademarks of the SKF Group. © SKF Group 2025 The contents of this publication are the copyright of the publisher and may not be reproduced (even extracts) unless prior written permission is granted. Every care has been taken to make sure the accuracy of the information contained in this publication but no liability can be accepted for any loss or damage whether direct, indirect or consequential arising out of the use of the information contained herein.
