SystemAir DKIR1 Attendant Manual

SMOKE DAMPER DKIR1 and DKIS1
Resistance class E 120 (v
600 ed
12
IMOS-Systemair 90043 Kalinkovo 146, Slovakia
1396 - CPD - 0058 EN 12101 - 8
Smoke damper:
- cycling
Fire resistance:
E 120 (v i↔o) S500C
600 ed 10000
E 120 (v i↔o) S1500C
600 ed
(see the page 3)
- maintenan. of t. cross section
- integrity E
- smoke leakage S
- mechanical stability
- cross section
Durability of operational reliability:
open and closing cycle
i ↔ o) S500C AA single or E
10000
1396
200 cycles - passes
AAsingle or
AAsingle
10000
(under E)
600°C
500 Pa and 1500 Pa
(under E)
(under E)
Pass
120 (v i ↔ o) S1500C
600 ed 10000
Installation manual download
EN
Smoke damper is a component of SHEVS (smoke and heat
exhaust ventilation systems) and has two safety positions:
1. open - to enable exhaust of heat and smoke via special fan
from fire compartment in which occur fire accident or
2. closed - to stop the spread of heat and smoke to the fire
compartment without fire.
Type of the smoke damper, class of the fire resistivity and production
date are mentioned on the label glued on the smoke damper.
EVERY SMOKE DAMPER MUST BE INSTALLED IN ACCORDANCE
WITH INSTALLATION MANUAL!
The installation manual is available on the webpage
www.systemair.com/Global/Support and includes:
• Permitted installation methods with detailed descriptions
• Fire resistance classes
• Types and parameters of activating mechanisms
• Electrical connections of activating mechanisms
• Operating conditions of the smoke dampers
• Operating Manual
• Functionality check
• Inspection instructions
• Warranty conditions
• Operational journal
AttendantSheet_PP-52_DKIR1_DKIS1_EN_201510
AA single
1396 - CPD - 0058
