Summary of Contents for ALIBI Vigilant Performance ALI-PT41-UZAI
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. ⚫ Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
- Page 3 Wrap the connection part and the cable ends tightly with waterproof tape. Make sure the tape is fully stretched during the process. Tighten the tape at both ends to prevent water leakage. Tighten Tighten Tighten Waterproof tape Wrap the unused cables together into a bundle 3.
- Page 4 5. (Optional) After the waterproof treatment is completed, put the cables into a waterproof junction box (purchased separately). CAUTION! The cable connector must not be exposed and must be kept away from water. Restore and fasten the device after dismounting. Place the power adapter in a power distribution box.
- Page 5 Packing List Contact your local dealer if the package is damaged or incomplete. The package contents may vary with device model. Waterproof components x 1 Tapered Sleeve of Waterproof Rubber L-key x 1 Network Cable Head Stopper Appearance...
- Page 6 2.1 Dimensions 2.2 Structure and Cable Connection 2.2.1 Structure The appearance and tail cables may vary with device model. You may use the L-key (supplied with some products) to loosen the screws on the junction box cover. 2.2.2 Cable Connection The actual tail cable may vary with device model.
- Page 7 Mount Your Camera 3.1 Installation Tools ⚫ ESD wrist strap or gloves ⚫ Marker ⚫ Electric drill ⚫ Straight screwdriver ⚫ Phillips screwdriver 3.2 (Optional) Insert Micro SD Card ⚫ Before you insert or remove the Micro SD card, be sure to disconnect power and wait till the camera stops operation;...
- Page 8 ⚫ For recommended SD card specifications, please contact your dealer or technical support. Use the straight screwdriver to loosen the screw (see the figure below). Rotate the front face of the camera until you can see the Micro SD card cover. Use the Phillips screwdriver to loosen the screws on the cover, then insert the Micro SD card into the slot.
- Page 9 3.3 Install the Camera Make sure the mounting position is strong enough to hold the camera. 3.3.1 Ceiling Mount Paste the drill template on the ceiling to locate the positions of the holes. Use aφ6-6.5mm drill bit to drill 30 mm-depth guide holes according to the positions marked by the template.
- Page 11 3.3.2 Pendant Mount dealer or technical support for details. Paste the drill template on the ceiling to locate the positions of the holes. Use a φ6-6.5mm drill bit to drill 30 mm-depth guide holes according to the positions marked by the template. Knock the plastic rivets into the holes and ensure that they are tightened up.
- Page 13 Paste the drill template on the ceiling to locate the positions of the holes. Use a φ6-6.5mm drill bit to drill 30 mm-depth guide holes according to the positions marked by the template. Knock the plastic rivets into the holes and ensure that they are tightened up. Use 4 screws to mount the bracket onto the wall.
- Page 14 Startup After you have installed the device, connect to the power adapter (purchased separately) to start up the device. Web Login Log in to the Web interface to manage and maintain the device. Open your Web browser, enter the camera's IP address in the address bar, and then press Enter.
- Page 15 All rights reserved. No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from Alibi Security (referred to as Alibi Security or us hereafter). The product described in this manual may contain proprietary software owned by Alibi Security and its possible licensors.
- Page 16 Liability ⚫ To the extent allowed by applicable law, in no event will Alibi Security be liable for any special, incidental, indirect, consequential damages, nor for any loss of profits, data, and documents.
- Page 17 Keep firmware up to date: It is recommended that your device is always upgraded to the latest version for the latest functions and better security. Visit Alibi Security's official website or contact your local dealer for the latest firmware.
- Page 18 ⚫ Verify that the device is properly installed before connecting it to power. ⚫ Do not remove the seal from the device body without consulting Alibi Security first. Do not attempt to service the product yourself. Contact a trained professional for maintenance.
- Page 19 ⚫ ⚫ Use the battery properly. Improper use of the battery such as the following may cause risks of fire, explosion or leakage of flammable liquid or gas. ➢ Replace battery with an incorrect type. ➢ Dispose of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery. ⚫...
- Page 20 ➢ Disposer d’une batterie dans le feu ou un four chaud, écraser mécaniquement ou couper la batterie. ⚫ Disposer la batterie utilisée conformément à vos règlements locaux ou aux instructions du fabricant de la batterie. Regulatory Compliance FCC Statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 21 Battery Regulation- (EU) 2023/1542 Battery in the product complies with the European Battery Regulation (EU) 2023/1542. For proper recycling, return the battery to your supplier or to a designated collection point.
