- Page 1 USER MANUAL VOICE EVACUATION & PUBLIC ADDRESS SYSTEM VA-6200MA VA-6200MS Thanks for using ITC Voice Evacuation& Public Address System. For better operation, please read this manual carefully before operating the system.
- Page 2 Notification WARNING To ensure the reliability of the equipment and the safety of personnel, please observe the following when installing, using and maintaining: ● If any of the following conditions are found, please immediately turn off the power, plug out and quickly contact your nearest dealer.
- Page 3 ● This equipment is only suitable for safe use at altitudes under 2000 meters. Precautions 1. The installation environment When installing the unit, in order to ensure the normal cooling of the host, should avoid the poor ventilation of the place or high temperature environment, to avoid direct sunlight. Recommend to install cabinet or other well-ventilated place indoor.
- Page 4 5. Agreement Please strictly follow the instructions in this manual. The software, hardware and appearance of this product will be upgraded and updated continually. The above changes will be made without notice. Non-professional maintenance personnel, do not remove the product, to avoid damage and electric shock.
- Page 5 Contents 1 Product renderings......................... 6 1.1 VA-6200MA Product design sketch（2U）...............6 1.2 VA-6200MS Product design sketch（2U）............... 6 2 Main function introduction......................7 2.1 VA-6200MA Function feature.................... 7 2.2 VA-6200MS Features......................8 3 Main technical parameters Specifications..................9 3.1 Electrical Specifications...................... 9 3.2 Performance Specifications....................9 4 Device function description......................
- Page 6 1 Product renderings 1.1 VA-6200MA Product design sketch（2U） FIGURE 1- 1 VA-6200MA Product renderings 1.2 VA-6200MS Product design sketch（2U） FIGURE 1- 2 VA-6200MS Product renderings...
- Page 7 2 Main function introduction 2.1 VA-6200MA Function feature Built-in 500W amplifier, integrated 8 power A + B independent dual speaker loop partition output, each partition has a LED indicator, independent volume adjustment (6 files), forcibly cut to output power 100V when receive alarm signal.
- Page 8 2.2 VA-6200MS Features Built-in 500W amplifier, integrated 8 power A + B independent dual speaker loop partition output, each partition has a LED indicator, independent volume adjustment (6 files), forcibly cut to output power 100V when receive alarm signal. ...
- Page 9 3 Main technical parameters Specifications 3.1 Electrical Specifications ① Power supply Voltage ~220-240V ± 20%, 50-60Hz Fuse Size 3.5A ② Stand-by electric source Voltage DC 24V ± 20%, 18A Fuse Size 30A 3.2 Performance Specifications ① Analog audio ...
- Page 10 Frequency response 80Hz ~ 16kHz Output impedance 470Ω Signal to noise ratio> 70dB ② Communication RS485 interface Backup equipment RS485 interface Support maximum baud rate of 38400bps Supports up to 19 Backup equipments ...
- Page 11 4 Device function description The bellowed is front panel introduction for controller VA-6200MA ( For VA-6200MS detailed function, please refer to VA-6200MA as they are with same front panel printing ): Figure 4- 1 VA-6200MA front panel design sketch 4.1 Front panel function description ...
- Page 12 The buttons function description as follows: S.No Buttons Function Mode function button; FM / USB / playing (Long press this button to forcibly turn on / off the machine) Previous song (long press to increase volume) Mp3 loop playback function button; (with Repeat One / Repeat ALL / Random / Repeat Folder mode.) Play / Pause (long press this button in FM mode to receive the station) No function button...
- Page 13 4.2 Rear panel function description Figure 4- 2 VA-6200MA rear panel design sketch ON for power on, OFF for power off. AC power input socket. DC POWER: 24V DC input interface, pay attention to positive and negative, Do not reverse! ...
- Page 14 IMPEDANCE: The button of impedance Calibration, when it is pressed, the system will calibrate and record the current impedance automatically. IP REST: The button to reset IP address, when it is press, the system will automatically reset the host IP address to the default value. ...
- Page 15 5 Operation Instructions 5.1 Self-test function 1. Power-on self-test: ① Connect the electricity AC power supply. ② Turn the power switch to the ON position. ③ Can hear the relay beat sound when connect the electricity. ④ Panel indicator will show the current system status. 2.
- Page 16 2) Wiring diagram of level trigger mode (Note: Dry contact trigger mode can be configured on the PC, can configure level trigger or LINE 3 as a sound source, after the emergency trigger can not restore the original play state.) 5.3 Local sound source play ...
- Page 17 5.4 PTT paging PTT button MP3 module Press the EMERGENCY button, then press the button on the PTT microphone to turn on the corresponding zone paging (need configure on PC). You can speak after the reminder tone. Please do not release the button during the speaking or it will automatically turn off paging and make a tone.
- Page 18 is orange and computer state is open (open) then connected to the speaker, press the self-test switch, and returned to normal state. 2) Short circuit test ------ Short circuit any zone output, do not need to press system fault self-test button on the front panel, Indicates light is orange and computer status short (short circuit).
- Page 19 1. Host volume control is control the volume of the entire machine, the adjustment will affect the 1 ~ 8 zone volume. Zone volume adjustment only adjusts the corresponding zone volume, does not affect other zones. 2. Amplifier output monitor Press the MONITOR button to turn on or off the monitor, Light on means amplifier monitor is turn on, light off means amplifier monitor is turn off.
- Page 20 5.9 Alarm voice replacement 1. Remove the TF card from the host and use a specialized card reader. 2. Plug in the computer, open the U disk, there are several folders. 3. Folder definition: (1) ALERT: warning voice folder (2) EVAC0: evacuation voice folder (3) PROMT: prompt voice folder (4) Other folders: ...
- Page 21 Functional memory function You can turn it off by the remote controller or long pressing the MODE button. After it is turned on, it can remember the function mode selected before. If you unplug the power cable and turn it on again, the default to keep the state when it was turned off last time.
- Page 22 Voice Evacuation Router address Table: DIP Switch Settings Voice Evacuation Controller Address...
- Page 23 Version 0.5...
