Analog Devices DC2784B-A Demo Manual page 11

PARTS LIST
ITEM QTY REFERENCE
31 1 R123
32 2 R124, R224
33 1 R137
34 1 R148
35 1 R203
36 1 R204
37 1 R205
38 2 R213, R223
39 1 R220
40 1 R229
41 1 R233
42 1 R234
43 1 R235
44 1 R236
45 2 SW1, SW2
46 2 U1, U2
47 1 U5
48 1 U6
49 1 U7
50 1 U8
Additional Demo Board Circuit Components
1 0 C14, C16, C17, C29, C31, C32, C34, C36, C40-
C44, C46-C56, C58,
2 0 COUT48-COUT51, COUT53-COUT57, COUT59,
COUT61, COUT64, COUT65, COUT67,
COUT70-COUT73, COUT76, COUT77, COUT79,
COUT82-COUT87, COUT89, COUT90-COUT92,
COUT94, CIN19-CIN24, CIN26-CIN32,
CIN34-CIN36
3 0 COUT52, COUT58, COUT60, COUT62,
COUT63, COUT66, COUT68, COUT69,
COUT74, COUT75, COUT78, COUT80,
COUT81, COUT88, COUT95, COUT96,
4 0 D2
5 0 R8, R27-R31, R109, R117, R120, R121,
R127, R130, R134, R138-R140, R144, R145,
R150-R152, R155, R157, R160, R208, R216,
R218, R219, R221, R226, R238-R245
6 17 R9, R91, R92, R112, R114, R132, R135,
R136, R146, R147, R149, R158, R202, R211,
R215, R222, R227
7 0 R104, R105, R122, R128, R141, R143, R153,
R156
8 0 R217
PART DESCRIPTION
RES., 1M, 5%, 1/10W, 0603, AEC-Q200
RES., 200Ω, 1%, 1/10W, 0603
RES., 2.43k, 1%, 1/10W, 0603, AEC-Q200
RES., 3.24k, 1%, 1/10W, 0603, AEC-Q200
RES., 681k, 1%, 1/10W, 0603
RES., 3.3Ω, 1%, 1/10W, 0603, AEC-Q200
RES., 82.5Ω, 1%, 1/10W, 0603, AEC-Q200
RES., 4.99k, 1%, 1/10W, 0603, AEC-Q200
RES., 15.8k, 1%, 1/10W, 0603, AEC-Q200
RES., 100k, 1%, 1/10W, 0603, AEC-Q200
RES., 100Ω, 1%, 1W, 0603, AEC-Q200
RES., 1.4k, 1%, 1/10W, 0603, AEC-Q200
RES., 154k, 5%, 1/10W, 0603, AEC-Q200
RES., 2Ω, 1%, 1/10W, 0603, AEC-Q200
SWITCH, SUBMINIATURE SLIDE
IC, LTM4700EY
IC, MEMORY, EEPROM, 2kb (256×8),
TSSOP-8, 400kHz
IC, µPWR LDO REG W/SHUTDOWN, SO-8
IC, TIMERBLOX: VOLTAGE-CTRL. PWM,
TSOT23-6
IC, SINGLE 100V, 85MHz, OP AMP ,
TSOT-23-5
CAP ., OPTION 0603
CAP ., OPT, 1210
OPT, D3L
DIODE, OPTION, SOD-323
RES., OPTION, 0603
RES., 0Ω, 1/10W, 0603
RES., OPTION, 0805
RES., OPTION, 1206
DEMO MANUAL
DC2784B-A
MANUFACTURER/PART NUMBER
VISHAY, CRCW06031M00JNEA
VISHAY, CRCW0603200RFKEA
VISHAY, CRCW06032K43FKEA
VISHAY, CRCW06033K24FKEA
VISHAY, CRCW0603681KFKEA
VISHAY, CRCW06033R30FKEA
VISHAY, CRCW060382R5FKEA
VISHAY, CRCW06034K99FKEA
VISHAY, CRCW060315K8FKEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW0603100RFKEA
VISHAY, CRCW06031K40FKEA
VISHAY, CRCW0603154KJNEA
VISHAY, CRCW06032R00FKEA
C&K COMPONENTS, JS202011CQN
ANALOG DEVICES, LTM4700EY#PBF
MICROCHIP , 24LC025-I/ST
ANALOG DEVICES, LT1129CS8-5#PBF
ANALOG DEVICES, LTC6992CS6-1#PBF
ANALOG DEVICES, LT1803IS5#PBF
OPTION
OPT
OPTION
OPTION
OPTION
VISHAY, CRCW06030000Z0EA
OPTION
OPTION
Rev. 0
11
