  • Page 1 F-FTS-B ASE OWNER’S MANUAL FUNCTIONAL TRAINING SYSTEM CAUTION! Read all precautions and instructions in this manual before using this equipment.
  • Page 2 THE AGE OF 35 OR HAVE PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE ASSEMBLING OR USING ANY FITNESS EQUIPMENT. FORCE USA FITNESS EQUIPMENT ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
  • Page 3 F-FTS-BASE PARTS LIST KEY NO. DESCRIPTION SPEC Q'ty Left Base Right Base Rear Post Left Rear Post Right Top Frame Left Top Frame Right Rear Frame Front Guide Shaft middle Frame φ19×1747 Guide Rod Frame Guide Rod Left Frame Guide Rod Right...
  • Page 4 Hook φ8 Bushing φ25×φ21.8×φ12.2×8 φ30×φ26×12 Decorative Cap Rubber Bumper φ38×φ7×15 Bar End φ38×φ9×8 Weight Selection Pin Bushing φ38×φ34×φ27×26 Adjustable Single Handle Ankle Strap Rubber Bumper φ62×φ19×25 φ96 Pulley φ72×25 Pulley Handle Grip φ24×φ18×227 Handle Grip φ23×520 Slide Guide □60×2.5×□50×25 End Cap φ25 Hex-lob Screw M6×12...
  • Page 5 Hex Bolts M12×90 Washer Aircraft Nut Philips Screw M6×16 End Cap □70×50 Crystal Tags 52×13 Allen Wrench...
  • Page 6 2 ×1 1 ×1 6 ×1 5 ×1 7 ×2 11 ×1 3 ×1 4 ×1 8 ×2 10 ×4 12 ×1 9 ×2 13 ×1 14 ×1 15 ×1...
  • Page 7 16 ×2 20 ×2 21 ×28 24 ×2 22 ×1 17 ×1 18 ×1 23 ×2 25 ×2 26 ×4 27 ×2 28 ×4 36 ×2 38 ×2 39 ×1 40 ×4 30 ×2 41 ×14 42 ×6 67 ×2 29 ×2...
  • Page 8 48 ×18 50 ×4 51 ×16 52 ×16 53 ×8 54 ×2 55 ×8 62 ×2 10 11 12 13 14 15...
  • Page 9 57 ×24 58 ×94 59 ×54 31 ×2 60 ×4 61 ×2 4＃×1 63 ×4 64 ×2 10 11 12 13 14 15...
  • Page 10 F-FTS-BASE × M1Q×70mm φ2Q×φ1Q.5 × × 1. Attach parts 9 and 4 to part 2 using M10x70mm bolts (55), washers (58) and M10 nuts (59) as shown in the diagram...
  • Page 11 × M1Q×70mm φ2Q×φ1Q.5 × × 1. Attach parts 9 and 3 to part 1 using M10x70mm carriage bolts (55), washers (58) and M10 nuts (59) as shown in the diagram...
  • Page 12 × M1Q×7Qmm φ2Q×φ1Q.5 × × 1. Attach part 7 to parts 3 & 4 using side plates (26), M10x70mm hex bolts (48), washers (58) and M10 nuts (59) as shown in the diagram.
  • Page 13 × M1Q×7Qmm φ2Q×φ1Q.5 × × 26 7 1. Place part 5 onto part part 3 and place part 6 onto part 4. 2. Attach part 7 using M10x70mm hex bolts (48) passing through parts 7, 5, 3 & 26 with washers (58) and M10 nuts (59).
  • Page 14 × 4 M10×70mm × 4 M8×40mm φ16×φ8.4 × 2 M10×75mm × 8 × 12 φ20×φ10.5 × 6 × 4 M8 1. Rest 2 x guide rods (10) within the indicated holes on part 1 ensuring the guide rods ends which have bolt holes are at the top. 2.
  • Page 15 × M10×75mm φ20×φ10.5 × × 1. Slide the left sliding block (14) onto a front guide shaft (8) so that the pop pin is on the same side as the numbered positioning holes. 2. Position the front guide shaft (8) onto part (1) with the numbered positioning holes on the sliding block facing inwards of the machine and ensuring the numbers are displayed in an upright manner.
  • Page 16 x 2 M1Qx9Qmm M12x9Qmm x 4 φ24xφ13.5 1. Attach a pulley bracket (24) to a selector rod (23) via an M12 nut (61). Rest the selector rod within the weight stack and secure with an M10x90 hex bolt (54) and M10 nut (59). Repeat this on the other side.
  • Page 17 x 36 φ20xφ10.5 x 16 M10x45mm M10x75mm 59 x 18 M10 52 41 9880 1. Feed the cable (29) through as shown in the diagram until the front end of the cable is secured to the rear of the swivel pulley bracket and the ball end of the cable is resting from the front of the swivel pulley bracket (16).
  • Page 18 φ2Qxφ1Q.5 6KG/13LB 12KG/26LB 18KG/39LB 24KG/52LB 30KG/65LB 36KG/78LB 42KG/91LB 48KG/104LB 54KG/120LB 60KG/133LB 66KG/146LB 72KG/159LB 78KG/172LB 84KG/185LB 90KG/198LB 21 36 1. Attach a carabiner (31) to each cable (29) and clip a handle (38) to each carabiner. 2. Attach the rack hook (22) to the chin up crossbar (13) and secure with washers (58) and M10 nuts (59).
  • Page 19 × M8×16mm φ16×φ8.4 × 1. Attach the weight stack cover mesh to the weight stack cover frames (28) and secure to the machine in the indicated positions with M8x16 hex bolts (51) and washers (57). Repeat on the opposite side. 2.
  • Page 20 59 58 52 41 53 59 64 45 59 58 41 32 52 62 55 52 58 53...
  • Page 21 F-FTS-B F-FTS-B-CABLECROSS F- STABILITYB F-FTS-B-SPOTTER F-FTS-B-STACK F- SEAT...
  • Page 22 PACKAGE LIST BOX 1： BOX 2： BOX 3： Part 3 Part 1 Part 5 Part 4 Part 2 Part 6 Part 8 Part 11 Part 7 Part 9 Part 12 Part 13 Part 10 Part 17 Part 14 Owner's Manual Part 18 Part 15 Part 20...
  • Page 23 Offering one of the best warranties on the market for your peace of mind, each piece of Force USA strength equipment is hand crafted for quality and we use state-of-the-art production methods for our entire range.
