- Page 1 CMI203 User′s Manual Version: 1.0...
- Page 2 Table of Contents Chapter 1 System Specification ....................3 Chapter 2 Outward ......................... 4 Chapter 3 Opening the chassis ....................5 Chapter 4 Assembly ........................6 Chapter 5 Installing the 3.5” HDD ....................7 CMI203 User’s Manual...
- Page 3 3. Avoid short-circuiting the lithium battery; this can cause it to superheat and cause burns if touched. 4. Do not operate the processor without a thermal solution. Damage to the processor can occur in seconds. 5. Do not block air vents at least minimum 1/2-inch clearance required. CMI203 User’s Manual...
- Page 4 HDD led x1, Power led x1, ATX power On/Off button x1, Reset button x1, DC 12V output connector x 1, D-Sub 9 GPIO connector x 1, COM connector x 3 LCM module (Optional) Flex ATX 180W or 250 power supply. 100-240V, 50-60Hz Power Supply CMI203 User’s Manual...
- Page 5 Chapter 2 Outward CMI203 User’s Manual...
- Page 6 Chapter 3 Open the chassis Fig. 3-1 Take off screws Fig. 3-2 The base stand CMI203 User’s Manual...
- Page 7 Fig. 4-2 Fix PSU cable Note: With the information of connector location, please refer to the user manual for mainboard. Fig. 4-3 Fix both CPU fan & PWR ON-OFF Fig. 4-4 ID723 cables. Note: With the information of connector location, please refer to the user manual for mainboard. Fig. 4-5 Connect two fan cable Fig. 4-6 Fix GPIO / system fan / USB cables Note: With the information of connector location, please refer to the user manual for mainboard. CMI203 User’s Manual...
- Page 8 Fig. 5-3 Fasten the four screws to lock HDD Fig. 5-4 Connect IDE cable to mainboard. and bracket together. Fig. 5-5 Connect IDE cable and power Fig. 5-6 Fasten the screw to lock HDD bracket connector to 3.5” HDD CMI203 User’s Manual...
