CHARACTERISTICS:
The HD67679-xxx-A1 and HD67679-xxx-B2 are BACnet slave / PROFINET Converter.
It allows the following characteristics:
Up to 2000 BACnet objects (Read+Write);
Two-directional information between BACnet and PROFINET;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67679 software on your PC in order to perform the following:
Define the parameter of BACnet line;
Define the parameter of PROFINET line;
Define BACnet objects that contain the data arrived from the PROFINET Master;
Define BACnet objects that contains the data to send to the PROFINET Master;
Update the device.
