CommScope FIST-MSC-MOBRA Installation Instructions

TC-1478-IP Rev. A, January 2021
1 Kit contents
N°
1 Mounting bracket
2 Baseplate
3 Hose-clamp
4 Bolt M8x12
5 Wall mount kit
2 Assemble mounting bracket
1
1 Mount the mounting bracket using the wall mount kit.
2 Slide the baseplate into the assembly.
3 Secure the baseplate with the 2 M8x12 bolts.
