Introduction
This user manual describes the Flex Frame-S
and provides directions for installation. Proce-
dures include: unpacking the frame, mounting
the frame on concrete floor or raised floor, and
grounding the frame. This user manual lists
related publications and how to obtain technical
assistance.
Related Publications
The following related publication is available at
•
Propel User Manual (TC-96307-IP) -- Manual listed only has info on the Propel panel
not the frame)
ip.pdf
Rev A
Flex Frame-S
https://www.commscope.com/globalassets/digizuite/944022-tc-96307-
User
Manual
Flex Frame-S
https://www.commscope.com/SupportCenter
© 2024 CommScope, Inc.
Page 1 of 14
Advertisement
Related Manuals for CommScope Flex Frame-S
Summary of Contents for CommScope Flex Frame-S
- Page 1 Contact Information ..... . .14 Introduction This user manual describes the Flex Frame-S and provides directions for installation. Proce- dures include: unpacking the frame, mounting the frame on concrete floor or raised floor, and grounding the frame.
- Page 2 The basic product consists of a 19-inch seismic rack with multiple cable managers, at the bottom of the frame. The Flex Frame-S has 24 rack units for fiber connector panel, slack storage not and multiple cable managers.
- Page 3 The identified features include the following: 19-Inch Seismic Rack yields basic rack and front view structure of the Flex Frame-S. •...
- Page 4 TC-01001504-IP 1.2 Dimensions and Specifications Figure 3 shows the Flex Frame-S dimensions. Figure 3. Flex Frame-S Dimensions Page 4 of 14. © 2024 CommScope, Inc.
- Page 5 Inspect the exterior of the shipping container(s) for evidence of rough handling that may have damaged the components in box. If damage is detected or if parts are missing, file a claim with the commercial carrier and notify CommScope Support Center at http:// www.commscope.com/SupportCenter...
- Page 6 Box containing hardware Installation 3.1 General The Flex Frame-S can be installed on a concrete floor or raised floor. Information is provided in separate sections for each scenario. Other steps are the same for concrete floor and raised floor installations.
- Page 7 TC-01001504-IP 3.3 Required Tools and Material The following tools are required for installing the Flex Frame-S. • Slot tip and Phillips screwdrivers - #1, #2, #3 • Level • Socket wrench • Set of sockets - 0.25 to 1 inch (8 to 25.4 mm) •...
- Page 8 Figure 6. Mark the location with the installation template, as shown. FRONT AISLE (4-FEET RECOMMENDED REAR AISLE MINIMUM) (3-FEET RECOMMENDED MINIMUM) CONCRETE FLOOR Figure 6. Determining Frame Location Page 8 of 14. © 2024 CommScope, Inc.
- Page 9 3. Set aside the installation template and drill four mounting holes in the concrete at the marks just made, as shown in Figure VACUUM IS REQUIRED DRILL HOLE DIMENSIONS: DIAMETER: 0.71-IN (18mm) DEPTH: 3-15/16-IN (100mm) Figure 8. Drilling Mounting Holes Page 9 of 14 © 2024 CommScope, Inc. .
- Page 10 TORQUE NUT WASHER THREADED ROD ANCHOR SLEEVE ANCHOR BOLT ASSEMBLED TAP ANCHOR BOLT WITH HAMMER WASHER TOUCHES CONCRETE 24992-A SIDE VIEW Figure 9. Installing Washer and Torque Nut on Threaded Rod Page 10 of 14. © 2024 CommScope, Inc.
- Page 11 TC-01001504-IP 5. Pre-torque the anchor bolt to approximately 30 foot-pounds (41 Newton meters). Refer to Figure FT-LB 24993-A TORQUE WRENCH Figure 10. Pre-torquing Anchor Bolt Page 11 of 14 © 2024 CommScope, Inc. .
- Page 12 Figure LOOSEN TORQUE NUT 24994-A TORQUE NUT WASHER REMOVE TORQUE NUT AND WASHER THREADED ROD Figure 11. Removing Torque Nut and Washer 3.6 Mounting the Frame on a Raised Floor Page 12 of 14. © 2024 CommScope, Inc.
- Page 13 TC-01001504-IP 7. The Flex Frame-S can be mounted on a raised floor using the CommScope Raised Floor Mounting Kit, 5/8” (FDF-ACC146). Figure 12 shows an exploded view of the kit components. To order the kit, refer to the following URL: https:// www.commscope.com/product-type/cabinets-panels-enclosures/frames-racks-...
- Page 14 3.7 Grounding Frame Figure 14 shows the location of the #10-32 ground studs on the front of the Flex Frame-S. The studs are intended for a ground strap with a 2-hole lug with 5/8-inch hole spacing. Ground with AWG wire conforming to local standards.
