TC-1334-IP
Rev A, Mar 2017
www.commscope.com
Content
1 General
1.1 General product information
1.2 Cable types
1.3 Symbols of this guide
1
General
1.1
General Product Information
CommScope's Mini-OTE 200 closure is a gel sealed fiber optic enclosure designed for splicing, termination and pass-through cable requirements in
fiber-to-the-X (FFTx) architectures.
The closure is available in 4,6, and 8 port versions DLX and 4 and 6 port versions full size hardened adapters; the housing is available in 2 colors,
black and gray.
The terminal is designed for use in wall, pole or handhole applications.
The closure has a maximum capacity of 24 splices, 2 trays of 12 splices each and contains an additional tray for fiber storage. The terminal housing
provides loop storage for microsheath or loose tube cable.
The Mini-OTE 200 allows for butt configurations with 4 wrap-around ports for multiple combinations of looped feeder cable (Ø 4 - 15 mm) and
branch-off cable (Ø 4 - 9 mm) where the feeder cables are positioned at the outside ports and the branch-off cables at the inside ports. TENIO
cable attachment is included as well as an external cable fixation integrated on the housing to absorb external forces on the cable.
1.2
Cable types
The Mini-OTE 200 is designed for microsheath or loose tube cables with an outside diameter up to 15 mm, and flat cable:
Feeder cable
Ø 4 -15 mm
Branch off cable
Ø 4 - 9 mm and flat (4.5x8.1 mm)
Fiber types include single fiber 250micron.
1.3
Symbols for this guide
Note
Presents useful information related to Installation Guide contents, the references and data related to the product's use, etc.
i
Caution
Describes situations where data loss and incorrect product operation may occur, and provides proper actions to take in these
situations.
!
Warning
Describes a situation where product damage and user injury may occur, and provides proper actions to take in these situations.
Mini-OTE 200
Mini-OTE 200
I N S T A L L A T I O N I N S T R U C T I O N
Advertisement
Table of Contents
Related Manuals for CommScope Mini-OTE 200 Series
Summary of Contents for CommScope Mini-OTE 200 Series
-
Page 1: Table Of Contents
General General Product Information CommScope’s Mini-OTE 200 closure is a gel sealed fiber optic enclosure designed for splicing, termination and pass-through cable requirements in fiber-to-the-X (FFTx) architectures. The closure is available in 4,6, and 8 port versions DLX and 4 and 6 port versions full size hardened adapters; the housing is available in 2 colors, black and gray. -
Page 2: Tools Required
Tools required Socket wrench 8 ( maximum outside Ø15mm) (mounting closure to wall) Scissors, Cutting pliers Socket wrench 1/4’’ (hose clamps) Stripping tools, shaving tools, cleaning alcohol and other tools required Phillips screw driver to prepare cables Part list Item # Description Item # Description... -
Page 3: Installation Splitter/Point To Point Module
Installation splitter/point-to-point module Slide in module Open protection cover by pulling (see arrows) and hinge protection cover downwards. Locking features to lock the module in the top cover are encircled on the picture. Back position Front position Hinge protection cover Visually check through openings in the cover of the module if hooks are well locked. -
Page 4: Connect Connectors To Dlx Adapters
Connect connectors to DLX adapters Remove the dust caps of the adapters and the connectors that need to be connected. Connect the connectors to the corresponding adapters respecting the color code and cross-over bend: connectors coming from the left side of the module go to the adapters on the right side (black arrow). -
Page 5: Bring Fibers To The Organizer
Bring fibers to the organizer Feed pigtails through slit in the organizer and push tube until the stop. There are 2 positions for the tubes on top of each other. First, use bottom position, secondly use top position. Then click tube in holder at the left side of the top cover. Take care tube is well positioned above hinge protection cover so it is not squeezed when you close the cover. -
Page 6: Cable Preparation
Cable preparation Loop capacity Make a window cut (see table). Make sure oscillation point is in the middle. Take out feeder tube and store other tubes in basket under organizer as described in section 6.4. It is recommended to straighten the loose tubes. #LT (to store) Ø... -
Page 7: Insert Feeder Loop To Storage Area
6.2.5 Aramid yarn Insert feeder loop to storage area Push one CTU in the holder (left position), take out feeder tube and roll up feeder loop under organizer. Push other CTU in the holder (right position). Other option is to make a loop of Ø130 mm (use tie wraps) and push loop under organizer. Feeder cables are positioned on the outside gel ports. -
Page 8: Securing Cable
Containment rings Break off small containment rings to contain branch off cables with a diameter of Ø 4 - 7 mm or break off large containment rings to contain feeder cables with a diameter of Ø 8.5 - 12 mm. Push ring over the cable in cavity above and under gel. Gel Inlet Use gel inlet for feeder cables with diameter Ø... -
Page 9: Splice Feeder To Splitter/Point To Point Module
Splice feeder to splitter/point to point module Organizer Tubes from feeder cable are routed in the outside slots [A]. Tubes from branch cables are routed in the inside slots [B] as shown on picture below. Pigtails from the modules in the top cover are routed in slot [C]. There is a possibility to route fibers from the first tray to the second and vice versa trough special designed slots in the tower. -
Page 10: End Cut
End cut Take out 1 tube before storing the loop under the basket and cut the feeder tube at 1 end (right side). Put a mark on the tube in the marking area (250 area) and strip tube to this point (10 -11cm from jacket end). Bring feeder fibers to the tray where the fibers from the connectors are stored and make fusion splice. -
Page 11: Branch Cable
Branch cable Prepare cable Remove jacket over 1m30 (1m fiber on tray). Install cable termination unit (CTU) as described in section 6.2 and attach in closure. Add containment following table in section 6.4. Secure cable with foam and tie-wrap or hose clamp to closure (section 6.5). Maximum diameter of the tube is Ø3mm. -
Page 12: Mounting The Closure
© 2017 CommScope, Inc. All rights reserved. web at www.commscope.com All trademarks identified by ® or ™ are registered trademarks or trademarks, respectively, of CommScope, Inc. For technical assistance, customer service, or to report any This document is for planning purposes only and is not intended to modify or supplement any specifications or warranties relating to missing/damaged parts, visit us at: CommScope products or services.
