PINK SMART PORTABLE MAGNETIC
UNDER DESK ELLIPTICAL
P2420
USER MANUAL
DO NOT STAND ON THE UNIT!
IMPORTANT! Please retain owner's manual for maintenance and adjustment instructions.
Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US: support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).
0
Advertisement
Table of Contents
Related Manuals for Sunny Health & Fitness P2420
Summary of Contents for Sunny Health & Fitness P2420
- Page 1 PINK SMART PORTABLE MAGNETIC UNDER DESK ELLIPTICAL P2420 USER MANUAL DO NOT STAND ON THE UNIT! IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained, and used properly. -
Page 3: Pre-Assembly Check List
PRE-ASSEMBLY CHECK LIST Description Spec. Qty. Main Frame Battery Thank You Card User Manual Ordering Replacement Parts (U.S. and Canadian Customers only) Please provide the following information in order for us to accurately identify the part(s) needed: ✓ The model number (found on cover of manual) ✓... -
Page 4: Adjusting The Tension
ADJUSTMENTS & USAGE GUIDE ADJUSTING THE TENSION Adjust the tension by rotating the Tension Control Knob (No. 8) clockwise to increase the level of resistance. Rotate the Tension Control Knob (No. 8) counter-clockwise to decrease the level of resistance. Tension levels are set at Level 1 being the lowest and Level 16 being the highest. - Page 5 EXERCISE METER BLUETOOTH 1. The Bluetooth icon will flash when the meter is on or wakes from sleep mode. If no Bluetooth connection is established within 3 minutes, the Bluetooth icon will turn off. 2. The Bluetooth icon will stay on when it is connected. WIRELESS HEART RATE 1.
- Page 6 FUNCTIONAL BUTTONS: MODE: To select functions. Press and hold the key for 3 seconds to reset the value to zero when the Bluetooth is not connected. Press and hold the MODE key for 6 seconds to disconnect from both the SunnyFit APP and the heart rate monitor;...
-
Page 7: Battery Installation And Replacement
BATTERY INSTALLATION & REPLACEMENT BATTERY INSTALLATION: 1. Take out 2 AAA batteries from the manual bag. 2. Remove the Meter (No. 9) from Main Frame (No. 1). 3. Install 2 AAA batteries into the battery case on the back of the Meter (No .9). Pay attention to the battery + and –... -
Page 8: App Connection
APP CONNECTION Connect Smart Equipment to SunnyFit App: 1. Scan to download SunnyFit from the app store: 2. Ensure that the Bluetooth function is turned on from your mobile device. 3. If this is your first time using the SunnyFit app, follow the in-app instructions to register for your free SunnyFit account and log in. -
Page 9: Exploded Diagram
EXPLODED DIAGRAM... -
Page 10: Parts List
PARTS LIST Description Spec. Qty. No. Description Spec. Qty. Φ17*Φ21*0.4 Main Frame Rubber Washer Φ200*19.5*Φ17*147.4 Left Pedal Frame Belt Wheel Right Pedal Frame Belt J300 Φ17 Crank C-clip Magnetic Board Bearing 6000 Idler Wheel Shaft Screw M5*15 Φ8.2*Φ16*1.5 Left Pedal Flat Washer Φ12*Φ10.2*6 Right Pedal...
