QCIOT31-ZMID4200POCZ

Sensor Pmod™ Board

Description

The QCIOT31-ZMID4200POCZ Board enables quick

prototyping of the

ZMID4200

Sensor for a custom system design. The ZMID4200

is an inductive position sensor IC with PWM, used for

absolute rotary and linear motion sensing. The board

provides a standard Pmod™ Type 6A (Extended I

connection for the on-board sensor to plug into any

MCU evaluation kit with a matching connector.

The QCIOT31-ZMID4200POCZ features Pmod

connectors on both sides of the board to allow

additional Type 6/6A boards to be connected in a

daisy-chained solution with multiple sensors on the

same MCU/MPU Pmod connector. Software support

present in the Renesas IDE

code generation to connect the sensor and the MCU,

thereby significantly reducing development time. With

its standard connector and software support, the

QCIOT31-ZMID4200POCZ is ideal for Renesas

Quick-Connect IoT

to rapidly create an IoT system.

Kit Contents

QCIOT31-ZMID4200POCZ Sensor Pmod Board

■

R15UH0019EU0100 Rev.1.00

Oct 24, 2024

PWM-to-Digital Output

(e2

studio) provides

Figure 1. QCIOT31-ZMID4200POCZ Sensor Pmod Board

Evaluation Board Manual

Features

Inductive principle

■

PWM output with programmable limits

■

Overvoltage, reverse polarity, ESD and short

■

circuit protection

10-bit resolution (PWM)

■

Standardized Type 6A Pmod connector supports

■

C Extended interface

Dual connectors allow pass-through signals for

■

daisy-chained solutions

Software support in e2 studio minimizes

■

development time with one-click code generation

Need help?

Do you have a question about the Sensor Pmod QCIOT31-ZMID4200POCZ and is the answer not in the manual?

Questions and answers

Summary of Contents for Renesas Sensor Pmod QCIOT31-ZMID4200POCZ

Page 1: Figure 1. Qciot31-Zmid4200Pocz Sensor Pmod Board
MCU/MPU Pmod connector. Software support Related Documents present in the Renesas IDE studio) provides code generation to connect the sensor and the MCU, ZMID4200 Datasheet ■...
Page 2: Table Of Contents
QCIOT31-ZMID4200POCZ Sensor Pmod Evaluation Board Manual Contents Functional Description ..........................3 Operating Environment ......................... 3 Setup................................4 Required or Recommended User Equipment ..................4 Required Software Tools and Versions ....................4 2.2.1 Connection Setup between QCIOT31-ZMID4200POCZ and ZMID4200STKI ......5 2.2.2 Calibrating the ZMID4200 IC ....................
Page 3: Functional Description
The QCIOT31-ZMID4200POCZ functions as PWM-to-Digital Output Sensor converter building block to create a custom system solution. Use the board individually or with a combination of other sensors by using the Pmod Type 6A interface (for a list of available sensors Pmod boards, see the Renesas Quick-Connect IoT web page).
Page 4: Setup
ZMID4200STKIT Inductive Position Sensing Starter Kit ■ US082-INTERPEVZ interposer board when using one of the Renesas MCU kits shown in Table 2 ■ Table 2. MCU Evaluation Kits Capable of Supporting Type 6A Pmods when used with the QCIOT31-ZMID4200POCZ Synergy...
Page 5: Connection Setup Between Qciot31-Zmid4200Pocz And Zmid4200Stki
QCIOT31-ZMID4200POCZ Sensor Pmod Evaluation Board Manual Figure 4. QCIOT31-ZMID4200POCZ and ZMID4200STKI Hardware Setup 2.2.1 Connection Setup between QCIOT31-ZMID4200POCZ and ZMID4200STKI To establish a connection between the two boards, connect the P1 connector on Starter kit with the J1 connector on QCIOT31 board as per shown below: ZMID4200STKI (P1) QCIOT31-ZMID4200POCZ (J1) Pin Number...
Page 6: Kit Hardware Connections
QCIOT31-ZMID4200POCZ Sensor Pmod Evaluation Board Manual Figure 5. QCIOT31 Hardware Setup with Linear Coil Kit Hardware Connections To setup the evaluation kit, see Figure 6 and use the following procedures: Figure 6. Evaluation Kit Connections Number Function Connect to Board Other Pmod connects here C pull-up resistors (R2 and R3) IRQ pull-up resistor (R1)
Page 7: Programming Interface
3. Programming Interface Programming of the system is accomplished through the Renesas IDE, studio. See the MCU evaluation kit documentation to set up the initial project in e2 studio. As the project is initialized, adding the ZMID4200 sensor to the project only takes a few steps.
Page 8: Board Design
Not Fitted Würth Elektronik 885012206046 Ceramic Capacitor, 10 pF, ±5%, 50V, 0603 (1608 Fitted Renesas GRM1885C1H100JA01D Metric) Renesas Inductive Position Sensor IC, Analog Fitted Würth Elektronik ZMID4200AI1R Output 14pin TSSOP Connector Header Through Hole, Right Angle 12 Fitted Würth Elektronik 61301221021 Position 0.100"...
Page 9: Coil Daughter Card Board Bom
QCIOT31-ZMID4200POCZ Sensor Pmod Evaluation Board Manual Reference Assembly Manufacturer Description Manufacturer Designator Note Part Number 12 Position Receptacle Connector 0.100" Fitted Samtec Inc. 613012243121 (2.54mm) Through Hole, Right Angle Gold Connector Header Through Hole 6 Position Fitted Harwin Inc. 61300611121 0.100"...
Page 10: Board Layout
QCIOT31-ZMID4200POCZ Sensor Pmod Evaluation Board Manual Board Layout 4.3.1 Pmod Base Board Layout Figure 10. Bottom Layer Figure 9. Top Layer Figure 11. Internal Plane-1 (GND) Figure 12. Internal Plane-2 (PWR) 4.3.2 Coil Daughter Card Board Layout Figure 14. Bottom Layer Figure 13.
Page 11: Metal Contact Board Layout
5. Ordering Information Orderable Part Number Description QCIOT31-ZMID4200POCZ ZMID4200 PWM-to-Digital Output Sensor US082-INTERPEVZ Pmod interposer board to convert Type 2A and 3A to Type 6A on older Renesas MCU kits 6. Revision History Revision Date Description 1.00 Oct 24, 2024 Initial release.
