QCIOT-RRH47000POCZ
QCIOT-RRH47000POCZ NDIR CO2 Sensor PMOD
Description
The QCIOT-RRH47000POCZ Evaluation Board
(RRH47000 EVB) demonstrates the functionality and
performance of the RRH47000 NDIR CO
The RRH47000 uses nondispersive infrared (NDIR)
technology to accurately measure CO
of the RRH47000 EVB is generic so that customers
can embed the sensor into their specific applications.
The board provides a standard Pmod
2
(extended I
C) connection for the onboard sensor to
plug into any required MCU evaluation kit with a
matching connector. The RRH47000 EVB can be
added to the end of a daisy-chained solution with
multiple Type 6/6A devices on the same MCU Pmod
connector.
The software support included with the Renesas IDE
2
(e
studio) allows for code generation to connect the
device and the MCU in order to significantly reduce
development time. With its standard connector and
software support, the RRH47000 EVB is ideal for the
Renesas Quick-Connect IoT to rapidly create an IoT
system.
R15UH0021EU0100 Rev.1.00
Jan 29, 2025
sensor.
2
. The design
2
TM
Type 6A

Figure 1. QCIOT-RRH47000POCZ NDIR CO2 Pmod

Evaluation Board Manual
Features
Accurate CO
measurements
2
Sensor outputs feature:
NDIR CO
sensor technology
2
Integrated temperature and humidity sensor
CO
measurement range: 400ppm to 5000ppm
2
CO
Accuracy: ± (30ppm + 3% of reading) for
2
the range 0 to 2000ppm, 0 to 50°C and 50
±10% RH
Current consumption: < 50mA at 1s sample time
2
I
C and UART interface
Long-term stability and long lifetime > 15 years
Standardized type 6A Pmod connector supports
2
I
C/SMBUS extended interface
Software support in e
development time with one-click code generation
Board Contents
QCIOT-RRH47000POCZ CO
2
studio minimizes
Sensor
2
Page 1
© 2025 Renesas Electronics

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QCIOT-RRH47000POCZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Renesas QCIOT-RRH47000POCZ

  • Page 1: Figure 1. Qciot-Rrh47000Pocz Ndir Co2 Pmod

    ■ Software support in e studio minimizes The software support included with the Renesas IDE development time with one-click code generation studio) allows for code generation to connect the device and the MCU in order to significantly reduce Board Contents development time.
  • Page 2: Table Of Contents

    Ordering Information ..............................17 Revision History ................................17 Figures Figure 1. QCIOT-RRH47000POCZ NDIR CO2 Pmod ....................... 1 Figure 2. RRH47000 Block Diagram ............................3 Figure 3. QCIOT-RRH47000 Pmod with EK-RA6M4 MCU Kit ....................4 Figure 4. QCIOT-RRH47000 Pmod (Top) ..........................5 Figure 5.
  • Page 3: Functional Description

    QCIOT-RRH47000POCZ Evaluation Board Manual Functional Description The RRH47000 EVB is intended as a quick-connect prototyping solution for a CO monitoring system. The board allows designers to quickly create CO monitoring systems. The EVB can measure CO ranges from 400ppm to 5000ppm.
  • Page 4: Software Installation And Usage

    SEGGER J-Link RTT Viewer ■ Sample code files (available on the QCIOT-RRH47000POCZ product page) 1.2.1 Software Installation and Usage Visit the Renesas website for the latest version of the e studio installer. The minimum FSP version supporting the QCIOT-RRH47000 Pmod is 5.7.0. Visit J-Link RTT Viewer to install the latest version of RTT Viewer.
  • Page 5: Board Design

    QCIOT-RRH47000POCZ Evaluation Board Manual Board Design Figure 4. QCIOT-RRH47000 Pmod (Top) Figure 5. QCIOT-RRH47000 Pmod (Bottom) R15UH0021EU0100 Rev.1.00 Page 5 Jan 29, 2025...
  • Page 6: Schematic Diagrams

    QCIOT-RRH47000POCZ Evaluation Board Manual Schematic Diagrams Bill of Materials Manufacturer Designator Description Manufacturer Part Number C1, C2 Capacitor, 0.1uF, 50V, SM KEMET C0603C104J5RACTU C3, C4 10uF, X5R, MLCC Ceramic capacitor, 0805 Samsung CL21A106KOQNNNG C5, C6 Ceramic Chip Capacitor 0402 47nF 16V...
  • Page 7: Board Layout

    QCIOT-RRH47000POCZ Evaluation Board Manual Manufacturer Designator Description Manufacturer Part Number Resistor 187K, Smt 0603 Yageo RC0603FR-07187KL Res Thick Film 0603 4.7 Ohm 1% 1/10W R2, R3 Vishay Dale CRCW06034R70FKEA ±100ppm/°C Molded SMD Paper T/R Fixed Resistor, Metal Glaze/thick Film, 0.1W, 49.9ohm, 75V, 1% ±Tol, 100ppm/Cel, Surface...
  • Page 8: Software Design

    This section provides an overview of the software implementation for the QCIOT-RRH47000 Pmod, which is based on the Renesas RA Family's Flexible Software Package (FSP). It also explains the project's code structure, the system's software modules, and the main system flow.
  • Page 9: Figure 13. Stack Configuration - Hal/Common

    QCIOT-RRH47000POCZ Evaluation Board Manual When you click configuration.xml in the project and select the Stack tab, a stack configuration appears (see Figure 13). Figure 13. Stack Configuration – Hal/Common R15UH0021EU0100 Rev.1.00 Page 9 Jan 29, 2025...
  • Page 10: Software Module Overview

    QCIOT-RRH47000POCZ Evaluation Board Manual main.c hal_entry.c rm_rrh47000.c rm_rrh47000_ rm_rrh47000.h api.h FSP Driver rm_common_i2c rm_ioport rm_i2c_master Figure 14. Code Dependency Graph Software Module Overview The RRH47000 demo project shows the basic use of FSP API calls to set up and read sensor data from the RRH47000.
  • Page 11: Algorithm Flowchart

    QCIOT-RRH47000POCZ Evaluation Board Manual 3.2.2 Algorithm Flowchart hal_entry Start g_comms_i2c_bus0_ quick_setup() g_comms_i2c_devic e0_quick_setup() g_rrh47000_sensor0 _quick_setup() While(1) g_rrh62000_sensor0 _quick_getting_data( print_rrh47000_sens or_data() Figure 15. Algorithm Flowchart The I C bus is opened by g_comms_i2c_bus0_quick_setup(). Then, the RRH47000 instance is opened by g_rrh47000_sensor0_quick_getting_data().
  • Page 12: Board Test

    QCIOT-RRH47000POCZ Evaluation Board Manual Call g_comms_i2c_device0_quick_setup() ■ ● Open I2C Communications device instance, this must be done before calling any COMMS_I2C_API. ■ Call g_rrh62000_sensor0_quick_setup() ● Open RRH62000 instance, this must be done before calling any RRH47000 API. ■ Continuously call g_rrh62000_sensor0_quick_getting_data() ●...
  • Page 13: Figure 17. Debug Configuration

    QCIOT-RRH47000POCZ Evaluation Board Manual 3. Go to the menu bar and select Run > Debug Configuration. Figure 17. Debug Configuration 4. Select Renesas GDB Hardware Debugging > rrh47000_Demo Debug. 5. Click the Debug button. Figure 18. Start Debug Mode R15UH0021EU0100 Rev.1.00...
  • Page 14: Figure 19. Running The Code

    QCIOT-RRH47000POCZ Evaluation Board Manual 6. Click the Play button to run the code. Figure 19. Running the Code R15UH0021EU0100 Rev.1.00 Page 14 Jan 29, 2025...
  • Page 15: Using Rtt Viewer

    QCIOT-RRH47000POCZ Evaluation Board Manual Using RTT Viewer 1. Open the J-Link RTT Viewer 2. Unplug the EKRA6M4 from your PC and then plug it back in. 3. Press S3 on the EK-RA6M4. 4. Click File > Connect. Figure 20. RRT Viewer 5.
  • Page 16: Figure 22. Rrh47000 Output

    QCIOT-RRH47000POCZ Evaluation Board Manual 6. Click OK. You should see the following output in the “All Terminals” tab. Figure 22. RRH47000 Output R15UH0021EU0100 Rev.1.00 Page 16 Jan 29, 2025...
  • Page 17: Website And Support

    QCIOT-RRH47000POCZ Evaluation Board Manual Website and Support Visit the following resources to learn about key elements of the RA family, download components, and related documentation, and get support: RA Product Information www.renesas.com/ra RA Product Support Forum https://community.renesas.com/mcu-mpu/ra/ RA Flexible Software Package www.renesas.com/FSP...
