Industrial Electronic Devices
User Manual
Revision 1.100
English
Modbus RTU / Modbus ASCII - Converter
(Order Code: HD67075-A1)
For Website information:
www.adfweb.com?Product=HD67075
For Price information:
www.adfweb.com?Price=HD67075-A1
Benefits and Main Features:
Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual Modbus RTU / Modbus ASCII
Document code: MN67075_ENG
For others products for Modbus:
Converters / Adapters
See also the following links:
www.adfweb.com?Product=HD67118
www.adfweb.com?Product=HD67119
www.adfweb.com?Product=HD67120
For others Gateways / Bridges:
Modbus RTU Master / Slave
See also the following links:
www.adfweb.com?Product=HD67001
www.adfweb.com?Product=HD67502
www.adfweb.com?Product=HD67011
www.adfweb.com?Product=HD67012
Modbus TCP Client to Modbus RTU Slave
See also the following link:
www.adfweb.com?Product=HD67510
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 1.100
Page 1 of 23
(Modbus RTU Slave)
(Modbus TCP Master)
(Modbus TCP Slave)
(CANopen)
(CANopen)
(CAN bus)
(CAN bus)
Phone +39.0438.30.91.31
Advertisement
Related Manuals for ADF Web HD67075-A1
Summary of Contents for ADF Web HD67075-A1
- Page 1 Revision 1.100 Page 1 of 23 Industrial Electronic Devices User Manual Revision 1.100 English Modbus RTU / Modbus ASCII - Converter (Order Code: HD67075-A1) For Website information: www.adfweb.com?Product=HD67075 For others products for Modbus: For Price information: Converters / Adapters www.adfweb.com?Price=HD67075-A1 See also the following links: www.adfweb.com?Product=HD67118...
-
Page 2: Table Of Contents
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 2 of 23 Industrial Electronic Devices UPDATED DOCUMENTATION: INDEX: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page Updated INDEX... -
Page 3: Security Alert
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 3 of 23 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Example Of Connection
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 4 of 23 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 5 of 23 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection Scheme for HD67075-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 6: Characteristics
Page 6 of 23 Industrial Electronic Devices CHARACTERISTICS: The HD67075-A1 is a Modbus RTU / Modbus ASCII – Converter. It allows for the following characteristics: Triple isolation between RS485 0 - Power Supply, RS485 0 – RS485 1, Power Supply – RS485 1. -
Page 7: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. The consumption depends to the code of the device. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device W/VA HD67075-A1 Caution: Not reverse the polarity power HD67075-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 8: Function Modes
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 8 of 23 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’: The first, with Dip1 in Off position (factory setting), is used for the normal working of the device. The second, with Dip1 in On position, is used for upload the Project/Firmware. -
Page 9: Leds
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 9 of 23 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 10: Ethernet
ETHERNET: The Ethernet connection must be made using Connector5 of HD67075-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable. -
Page 11: Rs485
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 11 of 23 Industrial Electronic Devices RS485: To terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet). -
Page 12: Use Of Compositor Sw67075
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 12 of 23 Industrial Electronic Devices USE OF COMPOSITOR SW67075: To configure the Converter, use the available software that runs with Windows called SW67075. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 13: New Configuration / Open Configuration
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 13 of 23 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “Modbus RTU / Modbus ASCII - Converter”... -
Page 14: Software Options
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 14 of 23 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 15 User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 15 of 23 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 16: Set Communication
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 16 of 23 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, Modbus RTU and Modbus ASCII. By pressing the “Set Communication”... - Page 17 User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 17 of 23 Industrial Electronic Devices In the field “Data Bits” the number of data bits used for the serial line communication is defined; In the field “Stop Bits”...
-
Page 18: Update Device
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 18 of 23 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. - Page 19 User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 19 of 23 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67075 device. Warning: If Fig.
-
Page 20: Mechanical Dimensions
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 20 of 23 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 5: Mechanical dimensions scheme for HD67075-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 21: Ordering Information
Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67075: Modbus RTU / Modbus ASCII - Converter Order Code: HD67075-A1 Converter Modbus RTU / Modbus ASCII Converter ACCESSORIES: Order Code: AC34107 Null Modem Cable Fem/Fem DSub 9 Pin 1,5 m... -
Page 22: Disclaimer
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 22 of 23 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 23: Warranties And Technical Support
User Manual Modbus RTU / Modbus ASCII Document code: MN67075_ENG Revision 1.100 Page 23 of 23 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
