Industrial Electronic Devices
User Manual
Revision 1.000
English
J1939 / CAN - Converter
(Order Code: HD67047-A1)
for Website information:
www.adfweb.com?Product=HD67047
for Price information:
www.adfweb.com?Price=HD67047-A1
Benefits and Main Features:
Very easy to configure
Electrical isolation
Temperature range: -40°C/85°C (-40°F/185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
Axis Solutions Pvt Ltd is the Authorized Distributor of
www.axisindia.in | info@axisindia.in
User Manual J1939 / CAN - Converter
Document code: MN67047_ENG
Revision 1.000
For others Gateways / Bridges:
J1939 to Modbus
See also the following links:
www.adfweb.com?Product=HD67215
CANopen to Modbus
See also the following links:
www.adfweb.com?Product=HD67001
www.adfweb.com?Product=HD67002
www.adfweb.com?Product=HD67004
www.adfweb.com?Product=HD67005
For others Gateways / Bridges:
For CAN bus 2.0A and/or CAN bus 2.0B to Modbus
See also the following links:
www.adfweb.com?Product=HD67011
www.adfweb.com?Product=HD67012
www.adfweb.com?Product=HD67014
www.adfweb.com?Product=HD67015
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Phone +39.0438.30.91.31
in India
Page 1 of 26
(Modbus TCP)
(Modbus RTU Master)
(Modbus RTU Slave)
(Modbus TCP Master)
(Modbus TCP Slave)
(Modbus RTU Slave)
(Modbus RTU Master)
(Modbus TCP Slave)
(Modbus TCP Master)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ADF Web HD67047-A1
Summary of Contents for ADF Web HD67047-A1
- Page 1 Revision 1.000 Page 1 of 26 Industrial Electronic Devices User Manual Revision 1.000 English J1939 / CAN - Converter (Order Code: HD67047-A1) for Website information: www.adfweb.com?Product=HD67047 For others Gateways / Bridges: for Price information: J1939 to Modbus www.adfweb.com?Price=HD67047-A1 See also the following links: www.adfweb.com?Product=HD67215...
-
Page 2: Table Of Contents
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 2 of 26 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 3 of 26 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 4 of 26 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 5 of 26 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67047-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 6: Characteristics
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 6 of 26 Industrial Electronic Devices CHARACTERISTICS: The HD67047 is a J1939 / CAN Converter. They have the following characteristics: Triple isolation between CAN - Power Supply, CAN – J1939, J1939 - Power Supply; Two-directional information between J1939 bus and CAN bus;... -
Page 7: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67047-A1 Caution: Do not reverse the polarity power HD67047-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 8: Function Modes
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 8 of 26 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’... -
Page 9: Leds
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 9 of 26 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 10: J1939
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 10 of 26 Industrial Electronic Devices J1939: To terminate the J1939 line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch B’ is at ON position. Cable characteristics: DC parameter: Impedance... -
Page 11: Can
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 11 of 26 Industrial Electronic Devices CAN: To terminate the CAN line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch C’ is at ON position. Cable characteristics: DC parameter: Impedance... -
Page 12: Ethernet
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 12 of 26 Industrial Electronic Devices ETHERNET: The Ethernet connection must be made using Connector4 HD67047 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. -
Page 13: Use Of Compositor Sw67047
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 13 of 26 Industrial Electronic Devices USE OF COMPOSITOR SW67047: To configure the Converter, use the available software that runs with Windows called SW67047. It is downloadable from the site www.adfweb.com and its operation is described in this document (this manual is referenced to the last version of the software present on our web site). -
Page 14: New Configuration / Open Configuration
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 14 of 26 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “J1939 / CAN - Converter”... -
Page 15: Software Options
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 15 of 26 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. -
Page 16: Set Communication
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 16 of 26 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, CAN and J1939. By Pressing the “Set Communication” button from the main window for SW67047 (Fig. 2) the window “Set Communication”... -
Page 17: Receive J1939
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 17 of 26 Industrial Electronic Devices RECEIVE J1939: By pressing the “Receive J1939” button from the main window of SW67047 (Fig. 2) the window “Receive J1939 Frames” appears (Fig. 4). The meaning of the fields of the table are: In the field... -
Page 18: Transmit J1939
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 18 of 26 Industrial Electronic Devices TRANSMIT J1939 By pressing the “Transmit J1939” button from the main window of SW67047 (Fig. 2) the window “Transmit J1939 Frames” appears (Fig. The meaning of the fields of the table are: field “Priority”... -
Page 19: Receive Can
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 19 of 26 Industrial Electronic Devices RECEIVE CAN: By pressing the “Receive CAN” button from the main window for SW67047 (Fig. 2) the window “Receive CAN Frames” appears (Fig. 6). In this section, it is possible to define the CAN frames that the converter will receive from CAN network. -
Page 20: Transmit Can
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 20 of 26 Industrial Electronic Devices TRANSMIT CAN: By pressing the “Transmit CAN” button from the main window of SW67047 the window “Transmit CAN Frames” appears (Fig. 7): in this section, it is possible to define the CAN frames that the converter will send to the CAN network. -
Page 21: Update Device
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 21 of 26 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. - Page 22 User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 22 of 26 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67047 device.
-
Page 23: Mechanical Dimensions
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 23 of 26 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 10: Mechanical dimensions scheme for HD67047-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 24: Ordering Informations
Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67047: J1939 / CAN – Converter Order Code: HD67047-A1 J1939 / CAN – Converter (Terminal Blocks connectors) ACCESSORIES: Order Code: AC34001 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC Order Code: AC34002 35mm Rail DIN - Power Supply 110V AC 50/60Hz –... -
Page 25: Disclaimer
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 25 of 26 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 26: Warranties And Technical Support
User Manual J1939 / CAN - Converter Document code: MN67047_ENG Revision 1.000 Page 26 of 26 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
