Industrial Electronic Devices
User Manual
Revision 1.001
English
RS232 / Optic Fiber - Converter
(Order Code: HD67072-B2)
RS485 / Optic Fiber - Converter
(Order Code: HD67073-B2)
USB / Optic Fiber - Converter
(Order Code: HD67074-B2)
for Website information:
Benefits and Main Features:
EMI/RFI and transient immunity
Data Rates up to 115200 bps
2 km (1.24 miles ) distance range
Industrial temperature range:
-40°C / 85°C (-40°F / 185°F)
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual RS232/S485/USB / Optic Fiber
Document code: MN67072_ENG
Revision 1.001
HD67072-B2, HD67073-B2, HD67074-B2
INFO:
www.adfweb.com
Page 1 of 18
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Web HD67072-B2
Summary of Contents for ADF Web HD67072-B2
- Page 1 Page 1 of 18 Industrial Electronic Devices User Manual Revision 1.001 English RS232 / Optic Fiber - Converter (Order Code: HD67072-B2) RS485 / Optic Fiber - Converter (Order Code: HD67073-B2) USB / Optic Fiber - Converter HD67072-B2, HD67073-B2, HD67074-B2 (Order Code: HD67074-B2)
-
Page 2: Table Of Contents
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 2 of 18 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you Page need to check that the following document is: INDEX Updated UPDATED DOCUMENTATION... -
Page 3: Security Alert
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 3 of 18 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Connection Scheme
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 4 of 18 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67072-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 5 User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 5 of 18 Industrial Electronic Devices Figure 2: Connection scheme for HD67073-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
- Page 6 User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 6 of 18 Industrial Electronic Devices Figure 3: Connection scheme for HD67074-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 7: Characteristics
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 7 of 18 Industrial Electronic Devices CHARACTERISTICS: Standards can be mixed and matched so RS-232 devices can be connected to RS-485 devices, or USB devices can communicate with RS485 devices, or RS232 devices can communicate with USB replacing a converter and isolator. -
Page 8: Power Supply
Vmin Vmax Consumption at 24V DC: Device W/VA HD67072-B2, HD67073-B2, HD67074-B2 Caution: Not reverse the polarity power HD6707X-B2 Note: The HD67074-B2 device cannot be fed only by the USB port (Connector2), it is necessary to use an external power supply on ‘Connector1’. -
Page 9: Function Modes
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 9 of 18 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’: The first, with Dip1 in Off position (factory setting), is used for the normal working of the device. The second, with Dip1 in On position, is used for upload the Project. -
Page 10: Leds
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 10 of 18 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode 1: Device State... -
Page 11: Rs232
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 11 of 18 Industrial Electronic Devices RS232: The connection from RS232 socket to a serial port must be made with a cable with these characteristics: It is recommended that the cable not exceed 15 meters. ADFweb.com Srl –... -
Page 12: Rs485
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 12 of 18 Industrial Electronic Devices RS485: The connection from the RS485 socket to the Personal Computer for updating the program must be made with a converter RS485 to USB or RS485 to RS232. -
Page 13: Baudrate/Parity/Stop Bit
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 13 of 18 Industrial Electronic Devices BAUDRATE/PARITY/STOP BIT: Acting on ‘Dip-Switch B’ it is possible to change the Baudrate, Parity and number of Stop Bit of the serial line and the fiber optic line. From Dip 1 to Dip 4 it is possible to set the Speed of the Serial line according to the following table: Speed [bps] Dip 1... -
Page 14: Fiber Optic Function
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 14 of 18 Industrial Electronic Devices FIBER OPTIC FUNCTION: By acting on ‘Dip-Switch C’ it is possible to select for each fiber, Tx and Rx, the logical state of 0 and 1. This Dip-Switch is inside the device, so you have to remove the top cover and act on the switches. -
Page 15: Updating Firmware
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 15 of 18 Industrial Electronic Devices UPDATING FIRMWARE: It is possible to update the Firmware of the device. For doing that, it is necessary to download from this link, www.adfweb.com/download/filefold/SW67072.zip, the program, install it and follow these instructions: Turn off the Device;... -
Page 16: Mechanical Dimensions
Document code: MN67072_ENG Revision 1.001 Page 16 of 18 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 5: Mechanical dimensions scheme for HD67072-B2, HD67073-B2, HD67074-B2 ORDER CODES: Order Code: HD67072-B2 RS232 / Optic Fiber - Converter Order Code: HD67073-B2 RS485 / Optic Fiber - Converter... -
Page 17: Disclaimer
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 17 of 18 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 18: Warranties And Technical Support
User Manual RS232/S485/USB / Optic Fiber Document code: MN67072_ENG Revision 1.001 Page 18 of 18 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: 1) Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
