Industrial Electronic Devices
User Manual
Revision 1.100
English
EtherNet/IP / M-Bus Master - Converter
(Order Code:
HD67077-B2-20, HD67077-B2-40,
HD67077-B2-80, HD67077-B2-160,
HD67077-B2-250)
For Website information:
www.adfweb.com?Product=HD67077-B2
For Price information:
www.adfweb.com?Price=HD67077-B2-20
www.adfweb.com?Price=HD67077-B2-40
www.adfweb.com?Price=HD67077-B2-80
www.adfweb.com?Price=HD67077-B2-160
www.adfweb.com?Price=HD67077-B2-250
Benefits and Main Features:
Very easy to configure
Up to 250 standard M-Bus devices connected to the
Converter
Power Supply 15...21V AC or 18...35V DC
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual EtherNet/IP / M-Bus Master - Converter
Document code: MN67077_ENG
For others M-Bus products see also the following link:
Converter M-Bus to
www.adfweb.com?Product=HD67021
www.adfweb.com?Product=HD67022
Analyzer / Scanner /Sniffer M-Bus
www.adfweb.com?Product=HD67031
Isolator/Repeater M-Bus
www.adfweb.com?Product=HD67032M
Gateway M-Bus / Modbus RTU
www.adfweb.com?Product=HD67029M-232
www.adfweb.com?Product=HD67029M-485
Gateway M-Bus / Modbus TCP
www.adfweb.com?Product=HD67044
Gateway M-Bus / CANopen
www.adfweb.com?Product=HD67051-B2
Gateway M-Bus / PROFIBUS
www.adfweb.com?Product=HD67053M
Gateway M-Bus Concentrator
www.adfweb.com?Product=HD67054M
Gateway M-Bus Slave / Modbus RTU master
www.adfweb.com?Product=HD67059M-232
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 1.100
Page 1 of 39
(RS232)
(RS485)
(on RS232)
(on RS485)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Web HD67077-B2-20
Summary of Contents for ADF Web HD67077-B2-20
- Page 1 Page 1 of 39 Industrial Electronic Devices User Manual Revision 1.100 English EtherNet/IP / M-Bus Master - Converter (Order Code: HD67077-B2-20, HD67077-B2-40, HD67077-B2-80, HD67077-B2-160, HD67077-B2-250) For others M-Bus products see also the following link: For Website information: Converter M-Bus to www.adfweb.com?Product=HD67077-B2 www.adfweb.com?Product=HD67021...
-
Page 2: Updated Documentation
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 2 of 39 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page Updated ... -
Page 3: Security Alert
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 3 of 39 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Example Of Connection
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 4 of 39 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 5 of 39 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67077-B2-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 6 Temperature range -40°C to 85°C. At the Converter can be connected up to 250 standard M-Bus devices. This number depends of the code expressed by the xxx number: HD67077-B2-20 support up to 20 M-Bus devices; HD67077-B2-40 support up to 40 M-Bus devices;...
-
Page 7: Power Supply
Vmin Vmax Consumption at 24V DC: Device No Load [W/VA] Full Load [W/VA]* HD67077-B2-20 HD67077-B2-40 HD67077-B2-80 HD67077-B2-160 HD67077-B2-250 * This value is with all the Slave M-Bus devices of the code (20, 40, 80, 160, 250) connected to the line... -
Page 8: Function Modes
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 8 of 39 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’... - Page 9 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 9 of 39 Industrial Electronic Devices LEDS: The device has got two LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
- Page 10 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 10 of 39 Industrial Electronic Devices ETHERNET/IP : The EtherNet/IP connection must be made using Connector3 of HD67077-B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps.
- Page 11 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 11 of 39 Industrial Electronic Devices USE OF COMPOSITOR SW67077: To configure the Converter, use the available software that runs with Windows called SW67077. It is downloadable on the site www.adfweb.com and its operation is described in this document.
-
Page 12: New Configuration / Open Configuration
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 12 of 39 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “M-Bus Master / EtherNet/IP - Converter”... -
Page 13: Software Options
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 13 of 39 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. -
Page 14: Set Communication
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 14 of 39 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, EtherNet/IP and M- Bus. By Pressing the “Set Communication”... - Page 15 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 15 of 39 Industrial Electronic Devices M-BUS By Pressing the “M-Bus” button from the main window for SW67077 (Fig. 2) the window “M-Bus Network” appears (Fig. 4). In the section “Nodes”...
- Page 16 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 16 of 39 Industrial Electronic Devices In the field “Send Reset App.” is checked, the converter sends the “Application Reset” command to the slave. In the field “Variables List”...
- Page 17 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 17 of 39 Industrial Electronic Devices ECTION ARIABLES Selecting the desired node it is possible to add a variable. In order to create a new variable it is necessary to fill these items: To use the created variable the field “Enable Variable”...
- Page 18 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 18 of 39 Industrial Electronic Devices In the field “VIFE” it is possible to select a sub-type of “Type of Data”; If the field “From BCD to Integer”...
- Page 19 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 19 of 39 Industrial Electronic Devices SECTION VARIABLES (BY POSITION): Selecting the desired node it is possible to add a variable. In order to create a new variable it is necessary to fill these items: To use the created variable the field “Enable Variable”...
- Page 20 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 20 of 39 Industrial Electronic Devices ASTE AND ELETE TEMS By pressing the right button of the mouse over an item (Variable or Node) it is possible to Copy, Paste and Delete.
- Page 21 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 21 of 39 Industrial Electronic Devices Example: 0x68 – Start Byte 0xBD – L Fied 0xBD – L Field 0x68 – Start Byte 0x08 – C Field 0x02 –...
- Page 22 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 22 of 39 Industrial Electronic Devices |_Volume Flow Ext. (m /min) |_24 |_Volume Flow Ext. (m |_32 |_Mass Flow (Kg/h) |_32 real |_Flow Temperature (°C) |_48 |_Return Temperature (°C) |_64 |_Temperature Difference (K)
- Page 23 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 23 of 39 Industrial Electronic Devices VIFE: |_ Period of tariff months(s) |_ Not Selected |_ Period of tariff year(s) |_ Credit of the nominal local legal currency units |_ dimensionless/ no VIF |_ Debit of the nominal local legal currency units |_ Volts...
- Page 24 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 24 of 39 Industrial Electronic Devices |_ per minute |_ # of exceeds of lower/upper limit |_ per hour |_ Date(/time) of begin/end of first/last lower/upper limit exceed |_ per day |_ Duration of limit exceed |_ per week...
- Page 25 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 25 of 39 Industrial Electronic Devices Swap Identification: This field is used for select the Swap mode of Identification Number. At the moment there are these possibilities: None;...
- Page 26 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 26 of 39 Industrial Electronic Devices To know the meaning of value read in the “Scale” byte position, you must follow this table (x = Value read in Scale location): Description Range Coding Range...
- Page 27 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 27 of 39 Industrial Electronic Devices Data type F: Min (0 … 59); Hour (0 … 23); Day (1 … 31); Month (1 … 12); Year (0 … 99); Time Invalid (0=Valid, 1=Invalid);...
- Page 28 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 28 of 39 Industrial Electronic Devices SINGLE SLAVE MODE FUNCTIONING: By checking the field “Single Slave Mode” it is possible to save 500 bytes of data for a single M-Bus Slave Device. For having the data it is necessary that the Master EtherNet/IP writes the first four bytes of his Input Data with the Primary or Secondary Address of the slave which want to receive the data.
-
Page 29: Update Device
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 29 of 39 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;... - Page 30 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 30 of 39 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67077 device. Warning: If Fig.
- Page 31 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 31 of 39 Industrial Electronic Devices SCAN & DECODE FUNCTION: “SCAN & DECODE” functions are integrated in the configurator software SW67077. It is possible to access to these functions by simple click on the “...
-
Page 32: Mechanical Dimensions
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 32 of 39 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7: Mechanical dimensions scheme for HD67077-B2-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 33: Ordering Informations
B: Modulbox 4M, 35mm DIN Rail mounting Device Family HD67077: EtherNet/IP / M-Bus Master - Converter Order Code: HD67077-B2-20 Converter EtherNet/IP / M-Bus Master (up to 20 slaves connected to M-Bus) Order Code: HD67077-B2-40 Converter EtherNet/IP / M-Bus Master (up to 40 slaves connected to M-Bus) -
Page 34: Plc Configuration
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 34 of 39 Industrial Electronic Devices PLC CONFIGURATION: The configuration and commissioning of the EtherNet/IP Converter as described on the following pages was accomplished with the help of the RSLogix 5000-software of Rockwell Automation. - Page 35 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 35 of 39 Industrial Electronic Devices 2) Edit the settings of the new Generic Ethernet Module. As shown in the screen shot below, the module was named “HD67077” and the IP-address assigned is 192.168.1.151.
- Page 36 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 36 of 39 Industrial Electronic Devices 3) After configuration completed, controller tags created. ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
- Page 37 User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 37 of 39 Industrial Electronic Devices 4) With “RSLinks Classic Lite”, after have done a network scan (RSWho), and finding the EtherNet/IP device, it is possible to load the EDS file for the device in order to have the “Module Info”...
-
Page 38: Other Regulations And Standards
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 38 of 39 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 39: Warranties And Technical Support
User Manual EtherNet/IP / M-Bus Master - Converter Document code: MN67077_ENG Revision 1.100 Page 39 of 39 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
