Industrial Electronic Devices
User Manual
Revision 2.102
English
M-Bus / RS232 - Converter
(Order Codes: HD67021-B2-20, HD67021-B2-40,
HD67021-B2-80, HD67021-B2-160, HD67021-B2-250)
M-Bus / RS485 - Converter
(Order Codes: HD67022-B2-20, HD67022-B2-40,
HD67022-B2-80, HD67022-B2-160, HD67022-B2-250)
for Website information:
www.adfweb.com?Product=HD67021
www.adfweb.com?Product=HD67022
for Price information:
www.adfweb.com?Price=HD67021-B2-20
www.adfweb.com?Price=HD67021-B2-40
www.adfweb.com?Price=HD67021-B2-80
www.adfweb.com?Price=HD67021-B2-160
www.adfweb.com?Price=HD67021-B2-250
www.adfweb.com?Price=HD67022-B2-20
www.adfweb.com?Price=HD67022-B2-40
www.adfweb.com?Price=HD67022-B2-80
www.adfweb.com?Price=HD67022-B2-160
www.adfweb.com?Price=HD67022-B2-250
Benefits and Main Features:
Very easy to configure
Triple electrical isolation
Temperature range: -40°C / 70°C (-40°F / 158°F)
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual M-Bus / RS232 / RS485
Document code: MN67021_ENG
For other M-Bus products see also the following link:
Gateway M-Bus / Modbus RTU
www.adfweb.com?Product=HD67029M-232
www.adfweb.com?Product=HD67029M-485
Converter M-Bus to
www.adfweb.com?Product=HD67030
Analyzer & Scanner M-Bus
www.adfweb.com?Product=HD67031
Extender and Repeater, M-Bus
www.adfweb.com?Product=HD67032
Gateway M-Bus / Modbus TCP
www.adfweb.com?Product=HD67044M
Gateway M-Bus Concentrator
www.adfweb.com?Product=HD67054M
Gateway M-Bus / PROFIBUS
www.adfweb.com?Product=HD67053M
Gateway M-Bus Slave / Modbus RTU master
www.adfweb.com?Product=HD67059M-232
Do you need to choose a device? do you want help?
Ask it to the following link:
User Manual
INFO:
www.adfweb.com
Revision 2.102
Page 1 of 25
(on RS232)
(on RS485)
(Ethernet)
www.adfweb.com?Cmd=helpme
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Web HD67021-B2-20
Summary of Contents for ADF Web HD67021-B2-20
- Page 1 Industrial Electronic Devices User Manual Revision 2.102 English M-Bus / RS232 - Converter (Order Codes: HD67021-B2-20, HD67021-B2-40, HD67021-B2-80, HD67021-B2-160, HD67021-B2-250) M-Bus / RS485 - Converter (Order Codes: HD67022-B2-20, HD67022-B2-40, HD67022-B2-80, HD67022-B2-160, HD67022-B2-250) For other M-Bus products see also the following link: for Website information: www.adfweb.com?Product=HD67021...
-
Page 2: Table Of Contents
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 2 of 25 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 3 of 25 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Connection Scheme
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 4 of 25 Industrial Electronic Devices CONNECTION SCHEMES: Figure 1a: Connection scheme for HD67021-B2-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 5 User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 5 of 25 Industrial Electronic Devices Figure 1b: Connection scheme for HD67022-B2-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 6: Characteristics
At the Gateway can be connected up to 250 standard M-Bus devices. This number depends of the code expressed by the xxx number: HD67021-B2-20 and HD67022-B2-20 support up to 20 M-Bus devices; HD67021-B2-40 and HD67022-B2-40 support up to 40 M-Bus devices;... -
Page 7: Power Supply
Vmax Consumption at 24V DC: Device No Load [W/VA] Full Load [W/VA]* HD67021-B2-20 / HD67022-B2-20 HD67021-B2-40 / HD67022-B2-40 HD67021-B2-80 / HD67022-B2-80 HD67021-B2-160 / HD67022-B2-160 HD67021-B2-250 / HD67022-B2-250 * This value is with all the Slave M-Bus devices of the code (20, 40, 80, 160, 250) connected to the line... -
Page 8: Function Modes
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 8 of 25 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’ of HD67021-B2-xxx / HD67022-B2-xxx: The first, with ‘Dip1 of Dip-Switch A’... -
Page 9: Leds
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 9 of 25 Industrial Electronic Devices LEDS: The HD67021-B2-xxx / HD67022-B2-xxx device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 10: M-Bus
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 10 of 25 Industrial Electronic Devices M-BUS: The M-Bus is a unpolarized bus. A two wire standard telephone cable (JYStY N*2*0.8 mm) is used as the transmission medium for the M-Bus. The maximum distance between a slave and the repeater is 350m;... -
Page 11: Rs485
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 11 of 25 Industrial Electronic Devices RS485 (for HD67022): To terminate the RS485 line with a 120Ω resistor, it is necessary to put dip 1 ON, like in figure. The maximum length of the cable should be 1200m (4000 feet). - Page 12 User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 12 of 25 Industrial Electronic Devices ETHERNET (for HD67021/22-B2-xxx): The Ethernet port is used for programming the device. The Ethernet connection must be made using Connector2 of HD67021/22-B2-xxx with at least a Category 5E cable. The maximum length of the cable should not exceed 100m.
-
Page 13: Use Of Compositor Sw67021
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 13 of 25 Industrial Electronic Devices USE OF COMPOSITOR SW67021: To configure the Converter, use the available software that runs with Windows called SW67021. It is downloadable from the site www.adfweb.com and its operation is described in this document (this manual is referenced to the last version of the software present on our web site). - Page 14 User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 14 of 25 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “M-Bus / RS232 / RS485 - Converter”...
-
Page 15: Software Options
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 15 of 25 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. -
Page 16: Set Communication
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 16 of 25 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of the M-Bus buses. By Pressing the “Set Communication” button from the main window for SW67021 (Fig. 2) the window “Set Communication”... - Page 17 User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 17 of 25 Industrial Electronic Devices UPDATE DEVICE (for HD67021M / HD67022M): By pressing the “Update Device” button it is possible to load the created Configuration into the device, and also the Firmware if is necessary, using the RS232 port.
- Page 18 User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 18 of 25 Industrial Electronic Devices UPDATE DEVICE (for HD67021-B2-xxx / HD67022-B2-xxx): By pressing the “Update Device” button, it is possible to load the created Configuration into the device;...
- Page 19 User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 19 of 25 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67021/22 device.
-
Page 20: Download Conf
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 20 of 25 Industrial Electronic Devices DOWNLOAD CONF.: By pressing the “Download Conf.” button, it is possible to download the Configuration that is inside the device into the opened project. After having set the type of hardware used, it is possible to download it by serial (HD67021/22M-20 or HD67021/22M-40/80/160/250) or by Ethernet (HD67021/22-B2). -
Page 21: Mechanical Dimensions
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 21 of 25 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7a: Mechanical dimensions scheme for HD67021/22-B2-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 22: Ordering Informations
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 22 of 25 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD6702x – B 2 - xxx Maximum number of slaves supported 20: up to 20 standard slaves (1.5mA consumption) connected to M-Bus 40: up to 40 standard slaves (1.5mA consumption) connected to M-Bus... -
Page 23: Accessories
Document code: MN67021_ENG Revision 2.100 Page 23 of 25 Industrial Electronic Devices Order Code: HD67021-B2-20 M-Bus / RS232 – Converter (up to 20 slaves connected to M-Bus) Order Code: HD67021-B2-40 M-Bus / RS232 – Converter (up to 40 slaves connected to M-Bus) Order Code: HD67021-B2-80 M-Bus / RS232 –... -
Page 24: Disclaimer
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 24 of 25 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 25: Warranties And Technical Support
User Manual M-Bus / RS232 / RS485 Document code: MN67021_ENG Revision 2.100 Page 25 of 25 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
