Summary of Contents for hager TYAS664D
- Page 1 Operating and assembly instructions KNX building management system KNX DALI actua- I > 185 mA GeW1E- Wrdth- Eoye2e secure U7Ts32 TP/S/X KNX Secure DALI 4gang broadcast actuator RGB(T)W TYAS664D...
-
Page 2: Table Of Contents
Contents Contents Introduction..............3 Safety instructions............5 Scope of delivery............6 Design and layout of the device........ 7 Function................ 8 System information......................8 systemlink commissioning....................8 easylink commissioning.......................8 Functional description......................8 DALI device types (DT)......................9 Short circuit protection....................... 9 Overload protection......................9 Operation.............. -
Page 3: Introduction
KNX-certified Supports KNX Data Secure Compatibility with DALI 2 Installation terminal with ac- Compatibility with Compatibility with Hager tuation opening KNX S-Mode (ETS) Easytool Suitable for use in Aus- Suitable for use in China Suitable for use in Morocco... - Page 4 Introduction Symbol Warning word Consequence on non-observance Danger Leads to serious injuries or death. Warning Can lead to serious injuries or death. Caution Can lead to minor injuries. Caution Can lead to device damage. Note Can lead to physical damage. Symbol Description Warning against electric shock.
-
Page 5: Safety Instructions
Safety instructions Safety instructions Electrical devices must only be installed and assembled by a qualified electrician in accordance with the relevant installation standards, guidelines, regulations, directives, safety and accident prevention directives of the country. Hazard due to electric shock. Disconnect before working on the device or load. Take into ac- count all circuit breakers that supply dangerous voltages to the device or load. -
Page 6: Scope Of Delivery
Scope of delivery Scope of delivery https://hgr.io/r/TYAS664D Fig. 1: TYAS664D scope of delivery... -
Page 7: Design And Layout Of The Device
GeW1E- Wrdth- Eoye2e secure U7Ts32 TP/S/X Fig. 2: Design and layout of the device TYAS664D Slide switch auto/ KNX bus connection terminal Connection of DALI ballasts Labelling field with cover Illuminated programming button Operation button for manual mode with status LED... -
Page 8: Function
Function System information Function System information This device is a product of the KNX system and corresponds to the KNX guidelines. Detailed spe- cialised knowledge obtained from KNX training courses is required for understanding. The device is KNX Data Secure-compatible. KNX Data Secure can be configured in the ETS project and offers protection against manipulation in building automation. -
Page 9: Dali Device Types (Dt)
Function DALI device types (DT) DALI device types (DT) In the DALI standard, devices are divided into 9 different device types (DT). The KNX Secure DALI 4gang broadcast actuator supports these device types. DALI device type (DT) – DT0, DT2 and DT3 describe the activation and behaviour of fluorescent and halogen lamps –... - Page 10 Function Overload protection Fig. 4: Overload detected...
-
Page 11: Operation
Operation Operation Switching manual mode on/off Bus voltage supply is present. Move the switch (Bild 2/1) to position Manual mode is switched on. The outputs can be controlled independently of each other via the operation buttons (Bild 2/6). Note! During manual mode, the controller is deactivated via the KNX bus. systemlink commissioning: Depending on the programming, manual mode is activated permanently or for a time peri- od configured using the application software. -
Page 12: Information For Qualified Electricians
Information for qualified electricians Installation and electrical connection Information for qualified electricians Installation and electrical connection Danger Electric shock when live parts are touched! An electric shock can lead to death! Disconnect all connection cables before working on the device and cover any live parts in the area! Caution Impermissible heating if load of the device is too high! - Page 13 Information for qualified electricians Installation and electrical connection Connecting the device The device is installed on the DIN rail in accordance with ISO 60715. Connect the connection cables for the power supply. CU = 0.75–2.5 mm² 10 mm 2.5 mm Fig.
- Page 14 Information for qualified electricians Installation and electrical connection Note! The control line and load cables can beprovided in a common cable, e.g. NYM-J 5 x 1.5 mm Use a control line type and cross-section that conforms to VDE regulations for 250 V lines, install the line in compliance with these regulations and with command voltage basic insu- lation.
-
Page 15: Commissioning
Information for qualified electricians Commissioning Commissioning The device can be programmed in three ways: – KNX systemlink mode (standard ETS programming) siehe , Seite 15 – KNX Secure mode siehe Inbetriebnahme im KNX Secure Modus , Seite 15 – KNX easylink mode siehe Easylink Inbetriebnahme , Seite 16 systemlink –... - Page 16 Information for qualified electricians Commissioning Fig. 11: Entering the QR code manually Fig. 9: Removing the de- Fig. 10: Scanning the QR code vice certificate from the de- vice (similar to illustration) Document all passwords and keep them in a safe place. Remove the device certificate (QR code) from the device and store it with the passwords.
- Page 17 Information for qualified electricians Commissioning Commissioning the device The device has been installed, connected and programmed correctly. Switch on the mains voltage at the outputs. Switch on the bus voltage. Depending on the parameter settings, the status LEDs of the operation buttons for manual mode light up.
-
Page 18: Dismantling
Information for qualified electricians Dismantling Dismantling Danger Electric shock when live parts are touched! An electric shock can lead to death! Isolate all connection cables before working on the device and cover any live parts in the area! Disconnecting the load cables All the cables delivering voltage to the device are switched off. - Page 19 Information for qualified electricians Dismantling Dismantling the device The bus connection cable and the load cables have been disconnected. Remove the device from the DIN rail. Fig. 17: Removing the device from the DIN rail Note! Dispose of the device in line with the corresponding guidelines of the respective coun- (siehe Entsorgung ) or, if you have a warranty claim, contact the point of sale (siehe...
-
Page 20: Appendix
Appendix Technical data Appendix Technical data KNX Medium TP1-256 Commissioning mode systemlink, easylink Mains power supply Supply voltage 230 V +10 %/-15 % 240 V ±6 % Mains frequency 50/60 Hz Own consumption on mains 900 mW KNX power supply Supply voltage 21 ... -
Page 21: Troubleshooting
Appendix Troubleshooting Troubleshooting Manual operation not possible. Switch (Bild 2/1) is not set to Move the switch to Manual operation is not enabled (systemlink). Enable manual operation via application software. Bus operation not possible. Bus voltage is not present. Check bus connection terminals for correct polarity. Check bus voltage by briefly pressing the programming button (Bild 2/5), red LED lights up if bus... -
Page 22: Rohs China
Appendix ROHS China ROHS China Regulatory Compliance Australia Disposal note Disposal note Correct disposal of this product (electrical waste). (Applicable in the European Union and other European countries with separate collection systems). This marking shown on the product or its documentation indicates that it should not be disposed of with other household waste at the end of its working life. - Page 23 Hager Controls BP10140 67703 Saverne Cedex France +33 (0) 3 88 02 87 00 info@hager.com hager.com 2024-10...
