    GV55LITE User manual GV55LITE GSM/GPRS/GPS Tracker User Manual TRACGV55LITEUM001 Revision: 1.02 http://www.queclink.com sales@queclink.com TRACGV3SUM001 - 1 -...
  • Page 2 TRACGV55LITEUM001 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession.

  • Page 3: Table Of Contents

    2.1. Check Part List ........................8 2.2. Parts List ..........................9 2.3. Interface Definition ......................9 2.4. GV55LITE User Cable Colour ..................10 3 . Getting Started ........................... 11 3.1. Opening the Case ......................11 3.2. Closing the Case ........................ 11 3.3.

  • Page 4: Table Index

    PART LIST ........................9 TABLE 4. DESCRIPTION OF 6 PIN CONNECTIONS ..............10 TABLE 5. GV55LITE USER CABLE COLOUR DEFINITION ........... 10 TABLE 6. ELECTRICAL CHARACTERISTICS OF IGNITION DETECTION ......13 TABLE 7. ELECTRICAL CHARACTERISTICS OF THE DIGITAL INPUTS ......13 TABLE 8.

  • Page 5: Figure Index

    GV55LITE User Manual Figure Index FIGURE 1. APPEARANCE OF GV55LITE ..................8 FIGURE 2. THE 6 PIN CONNECTOR ON THE GV55LITE ............9 FIGURE 3. OPENING THE CASE ....................11 FIGURE 4. CLOSING THE CASE ....................11 FIGURE 5. SIM CARD INSTALLATION ..................12 FIGURE 6.
  • Page 6 GV55LITE User Manual Revision History Revision Date Author Description of change 1.01 2012-7-31 Owen Feng Initial 1.02 2012-11-08 Owen Feng Change some pictures TRACGV55LITEUM001 - 6 -...

  • Page 7: Introduction

    GV55LITE User Manual 1. Introduction The GV55LITE is a powerful GPS locator designed for vehicle or asset tracking. It has superior receiver sensitivity, fast TTFF (Time to First Fix) and supports Dual-Band GSM frequencies 850/900/1800/1900, its location can be monitored in real time or be periodically tracked by a backend server or other specified terminals.

  • Page 8: Product Overview

    GV55LITE User Manual 2. Product Overview 2.1. Check Part List Before starting, check all the following items have been included with your GV55LITE. If anything is missing, please contact your supplier. Figure 1. Appearance of GV55LITE TRACGV55LITEUM001 - 8 -...

  • Page 9: Parts List

    User Cable DATA_CABLE_M (Optional) 2.3. Interface Definition The GV55LITE has a 6 PIN interface connector. It contains the connections for power, I/O. The sequence and definition of the 6PIN connector are shown in following figure: Figure 2. The 6 PIN connector on the GV55LITE...

  • Page 10: Gv55Lite User Cable Colour

    Ignition input, positive trigger Digital input, negative trigger OUT2 Open drain, 150mA max OUT1 Open drain, 150mA max ,with latch circuit 2.4. GV55LITE User Cable Colour Table 5. GV55LITE User Cable Colour definition Definition Color Cable Black White Orange OUT2...

  • Page 11: Getting Started

    GV55LITE User Manual 3 . Getting Started 3.1. Opening the Case Figure 3. Opening the Case Insert the triangular-pry-opener into the gap of the case as shown below, push the opener up until the case unsnapped. 3.2. Closing the Case Figure 4.

  • Page 12: Installing A Sim Card

    GV55LITE User manual 3.3. Installing a SIM Card Open the case and ensure the unit is not powered (unplug the 6Pin cable). Slide the holder right to open the SIM card. Insert the SIM card into the holder as shown below with the gold-colored contact area facing down taking care to align the cut mark.

  • Page 13: Ignition Detection

    IGN signal can be configured to start transmitting information to backend server when ignition is on; and enter power saving mode when ignition is off. 3.6. Digital Inputs There are one general purpose digital inputs on GV55LITE. It is negative trigger. Table 7. Electrical Characteristics of the digital inputs Logical State...

  • Page 14: Digital Outputs

    Typical Digital Input Connection 3.7. Digital Outputs There are two digital outputs on GV55LITE. All are of open drain type and the maximum drain current is 150mA. Each output has the built-in over current and recovery PTC fuse Figure 9.
  • Page 15 GV55LITE User manual Table 8. Electrical Characteristics of Ddigital Outputs Logical State Electrical Characteristics Enable <1.5V @150mA Disable Open drain Figure 10. Typical Connection with Relay Figure 11. Typical Connection with LED Note: 1 - OUT1 will latch the output state during reset.

  • Page 16: Device Status Led

    LED ON is 0 External power in and LED ON is 1 Table 9. Definition of Device status and LED GV55LITE has three status led that GSM GPS PWR led. Figure 12. GV55LITE LED on the Case Note: 1 - GSM LED cannot be configured.
