CAME FTL-P KIT Quick Setup Manual

CAME FTL-P KIT Quick Setup Manual

Complete kit for a pair of swing gates weighing up to 200kg per leaf / max. width 2m
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAME.COM/UK
FTL-P
kit
Complete kit for a pair of swing gates weighing
up to 200kg per leaf / max. width 2m
QUICK SETUP GUIDE
Typical gate setup & geometry
Gate motor manual release
Kit wiring diagram
Control panel guide & safety
TO BE READ IN CONJUNCTION WITH THE FULL INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FTL-P KIT and is the answer not in the manual?

Questions and answers

Related Manuals for CAME FTL-P KIT

Summary of Contents for CAME FTL-P KIT

  • Page 1 CAME.COM/UK FTL-P Complete kit for a pair of swing gates weighing up to 200kg per leaf / max. width 2m QUICK SETUP GUIDE Typical gate setup & geometry Gate motor manual release Kit wiring diagram Control panel guide & safety...

  • Page 2: Table Of Contents

    CONTENTS Control Panel: Kit Contents Quick Start Guide Safety Instructions Control Panel: Programming Transmitters Typical Gate Setup Control Panel: Safety Geometry Optional Accessories Manual Release Instructions Kit Wiring Diagram FTL-P: KIT CONTENTS FTL20DGC FTL20DGS AF43S Motor with built-in ZL60 Motor Radio Frequency Card control panel topd4Fks...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS When correctly installed in compliance to installation instructions and adhering to all current electrical, mechanical and manufacturer regulations, your automation system will provide a high degree of safety and problem free operation. Please take note of the following warnings that must be followed in order to prevent accidents during your gate operation: •...

  • Page 4: Typical Gate Setup

    FTL: TYPICAL GATE SETUP OUTSIDE OF GATES INSIDE OF GATES FTL Motor Flashing Light (optional) 2nd set of Photocells (optional) Control Panel Selector Keypad (optional) Mechanical End Stop (not supplied) Reception Antenna Photocells (on outside of gate posts) Photocell column (optional accessory) CONTROL PANEL •...

  • Page 5: Preliminary Checks

    FTL20DGC: GEOMETRY Preliminary checks Tick 1. Check that the gate structure is sturdy enough, the hinges work efficiently and that there is no friction between the fixed and moving parts 2. Make sure that measurement does not exceed the value shown in the reference table 3.

  • Page 6: Manual Release Instructions

    FTL: MANUAL RELEASE 1. Open the hatch covering the lock. Insert trilobe key into lock, turn it counter-clockwise and turn the release ALWAYS isolate the power supply as lever instructed by your installer (even in a power cut). 2. With your other hand firmly open the gate. The gate should be manually released.

  • Page 7: Wiring Diagram

    230V FTL-p: wiring diagram ZL60 Control Panel AF43S Plug-in TOP-A433N Antenna 10 2 TX C NC TX 2 Cable/length RG58 Max. 5m Mains Supply 230 V AC Cable/length 1m - 20m = 3 Core 1.5mm Photocells 20m - 30m = 3 Core 2.5mm Cable/length RX 4 Core 0.5mm Flex The Earth cable should...
  • Page 8 Safety inputs should now be configured and the gate force tested as required. Please refer to the full manual to complete the commissioning. Should the gates not operate as suggested above, call CAME helpline 0115 921 0430 for technical support.
  • Page 9 Once deletion is complete, the PRG LED stays lit and buzzer sounds off for one second. Set all the Dip switches down to the off position. Should the transmitter not operate as suggested above, call CAME helpline 0115 921 0430 for technical support.

  • Page 10: Safety Inputs

    FTL-p: ZL60: SAFETY ACCESSORIES SAFETY INPUTS FUNCTIONS > C1 Input, CX Input REOPENING DURING CLOSING • When the automation is in its closing cycle and the safety circuit is triggered the automation will stop and reverse its motion until it reaches its fully open position again.
  • Page 11 FTL-p: ACCESSORIES Code(s) Description RADIO KEYPAD SELECTORS 806SL-0170 SELT1W4G - Surface-mounted, 433.92 MHz radio-frequency keypad selector, 12-keys, with blue backlighting. 25 savable codes and password to access the programming mode. Settable in Rolling Code or Fixed Code mode. RAL7024 Grey colour. 806SL-0180 SELT1W8G - Surface-mounted, 868.35 MHz radio-frequency keypad selector, 12-keys, with blue backlighting.
  • Page 12 YOU MAY NOT EVEN PARTIALLY REPRODUCE THIS DOCUMENT CAME RESERVES THE RIGHT TO MAKE ANY CHANGES TO THIS DOCUMENT AT ANY TIME THE DATA AND INFORMATION SHOWN IN THIS CATALOGUE ARE SUBJECT TO CHANGE WITHOUT OBLIGATION TO GIVE PRIOR NOTICE BY CAME S.P.A, E&OE CAME S.p.A.
