AIPER Seagull Pro Manual

Structure

Structure

Specifications & Working Conditions

  1. Pool Size: 1600 sq. Ft/150m2
  2. Charger Input: 100-240V, 60/50Hz, 5A
  3. Charger Output: 29.4V/3A
  4. Charging Time: 3-4h
  5. Battery Life: Up to 150 Minutes
  6. IP Grade: IPX8 Waterproof
  7. Max Water Depth: 10 ft (3m)
  8. Motor Power: 70W
  9. Battery Pack: 7800mAh
  10. Battery Pack Voltage: 25.2V


Your Aiper pool cleaner is best used in the water conditions detailed below.

  • Temperature: 50-95ºF (10-35ºC)
  • pH Value: 7.0-7.4
  • Chlorine: Maximum 4 ppm
  • NaCl: Maximum 5000 ppm

Using Your Aiper Pool Cleaner

  1. The machine is suitable for cleaning floors, walls, and water lines up to 1600 sq. ft./150m2.
    Using Your Aiper Pool Cleaner

Installation

  1. Lift the tail end of the upper shell to open and gain access to the interior of the device.
    Installation - Step 1
  1. Insert the filter basket into the open slot as indicated in the graphic.
    Installation - Step 2
  2. After installing the filter basket, press down on the tail of the upper shell to close the device.
    Installation - Step 3

Operating Your Device

  1. Turn the dial clockwise to activate each cleaning mode. There are three cleaning modes to choose from.
    Operating Your Device - Step 1
    Auto Mode: Floor and Wall Cleaning

The machine will clean the pool floor and wall in turn. After cleaning the pool floor, wall cleaning will be conducted. When the battery reaches below 10%, the machine will stop cleaning and remain parked near the wall of your pool.
The machine will clean the pool floor along the "S"-shaped route (Wave-Path™ Navigation Technology ) without climbing the wall.
Operating Your Device - Step 2
Floor Cleaning Mode

The machine will clean the wall along the "N"-shaped route.
No floor cleaning will be carried out under this mode.
Operating Your Device - Step 3
Wall Cleaning Mode

  1. Place your device into your pool. Your device will begin cleaning within 10 seconds of reaching your pool's floor.
    Operating Your Device - Step 4
  1. After completing its cleaning cycle, or when the battery is low, your device may be retrieved from the pool using the provided hook. The unique design of the spring plate allows for rapid drainage of the device when taken out of the pool.
    Operating Your Device - Step 5

Disassembly and Cleaning

  1. Lift the rear end of the top shell to check the filter basket.
    Disassembly and Cleaning - Step 1
  2. Detach the fasteners to release the basket from the device.
    Disassembly and Cleaning - Step 2
  3. Open the tab of the filter basket.
    Disassembly and Cleaning - Step 3
  4. Remove any trash, wash the filter basket with water, and reinsert the filter basket into the device.
    Disassembly and Cleaning - Step 4

Charging

  1. Charging
    Fully charge your Aiper pool cleaner before using it to clean your pool.
  • Switch off the power before charging, otherwise the device cannot be recharged, and a rapid alarm will be activated.
  • Please remove the silicone plug before charging.
  • Wipe dry the charging port before charging your device.
    Charging - Step 1
  1. Please plug the silicone plug back in after charging or before cleaning your pool.
    Charging - Step 2

Maintenance & Storage

Replacement Instructions for wheel

  1. Lift up the wheel cover marked with an "A."
    Replacement Instructions for wheel - Step 1
  2. Remove the screws fixed to the wheel.
    Replacement Instructions for wheel - Step 2
  3. Remove the shaft and sleeve cover of the wheel for complete disassembly.
    Replacement Instructions for wheel - Step 3

Replacement Instructions for Rolling Brush Belt

  1. Locate the back side of the rolling brush belt and peel back the silicone buckle attached to the mounting slot.
    Replacement Rolling Brush Belt - Step 1
  2. Once all the silicone buckles are removed, replace the rolling brush belt with a new one. Align the silicone buckles with the mounting slots, and press to secure the buckles into each slot.
    Replacement Rolling Brush Belt - Step 2

LED Indicator

Machine Condition Indicator Condition Sound Description
Battery State The corresponding mode indicator and ring indicator are always on. A "ding" sound will
occur
time the button is turned.
The indicators color will relate to the device's battery status. Green: >90%
Blue: 50-89%
Yellow: 10-49%
Red: <9%
Charging Operating Property The Switch icon indicator is always on; the ring indicator flashes slowly. No sound.

When charging, the ring indicator will flash different colors corresponding to the appropriate battery states.

After being fully charged, the machine will automatically stop charging, and the ring indicator will turn green.

Operating Improperly The mode indicator is off. Constant and rapid alarm

If the switch icon indicator is disabled or a cleaning mode is enabled, the mode indicator will turn on, the ring indicator is off and the machine is not charging.

To charge the device, turn the button to the switch icon.

Mode Selection The mode indicator is always on. A "ding" sound will occur every time the button is turned.
  1. Turn the button clockwise to select the cleaning mode: Auto (Floor+Wall), Floor Only, or Wall Only.
  2. Turn button back counterclockwise to the original position to power off your device.
Operation Normal The mode indicator and the ring indicator are always on. No sound. The ring indicator will be in different colors corresponding to the battery status. Green: >90%
Blue: 50-89%
Yellow: 10-49%
Red: <9%
Abnormal The ring indicator is flashing in red. Constant and rapid alarm. Failure: electrical leakage, water blockage, etc.
Shutdown Indication All indicators are off. A "ding" sound. Turn the button back counterclockwise to the original position and your device will shut down.

Packing List

NO. Name Model QTY(pc)
1 Cleaner Aiper Seagull Pro 1
2 Charger / 1
3 Retrieval Hook / 1
4 User Manual / 1
5 Filter Basket / 1

Aiper Customer Service

US
Toll-Free: 1-866-850-0666

AU
Toll-Free: Email: service@aiper.com
Facebook: @AiperOffcial

Scan for Video Guide

Scan the GR Code to Access Customer Support

Important Safety Precautions

Please read this manual carefully and use your Aiper pool cleaner in accordance with the manual instructions. Aiper is not liable for any losses or injuries caused by improper use of this device.

For your safety and optimal performance of this device, please read and follow the following suggestions.

  1. Do not operate your Aiper pool cleaner while people or animals are in the pool.
  2. Turn the cleaner off while not in use or while performing maintenance.
  3. Do not allow children to ride the Aiper pool cleaner under any circumstances. Please supervise children when they are around an operational Aiper pool cleaner.
  4. Use only authorized Aiper power adapters.
  5. The adapter cord should only be replaced by a qualified electrician or Aiper Customer Care.
  6. It's suggested to plug the power adapter into a power strip or surge protector and not directly into an electrical outlet.
  7. Ensure your device is powered off and the charging port is dry before charging. While charging, your Aiper pool cleaner should be kept in a cool place. Do not cover your Aiper pool cleaner while charging as this may cause components to overheat.
  8. Please store the machine indoors or in a cool place when not in use.
  9. Do not run your Aiper pool cleaner out of the water as it may lead to overheating.
  10. Only certified professionals should disassemble the sealed driving kit of your Aiper pool cleaner.
  11. Do not operate your Aiper pool cleaner and pool filter simultaneously.
  12. The oil sealing around the motor contains grease, which may cause a small amount of water pollution if the motor is damaged. If you believe there is a leak, stop using the unit immediately.
  13. Do not pierce the shell of your Aiper pool cleaner, throw, or damage the cleaner intentionally.
  14. When putting your device into the water, the front of the machine must face upwards and should never be placed upside down or directly thrown into the swimming pool.

Please read this user manual carefully before operating the device.
