Summary of Contents for Aiper Scuba X1 Pro Max
- Page 1 CORDLESS ROBOTIC POOL CLEANER Original Instructions Aiper Scuba X1 Pro Max User Manual FRANÇAIS 丨 ESPAÑOL 丨 PORTUGUÊS ITALIANO 丨 DEUTSCH 丨 ENGLISH...
- Page 3 LANGUAGE Manuel d’utilisation ----------------------------- 1 Manual de usuario ------------------------------- 22 Manual do utilizador ----------------------------- 43 Manuale utente --------------------------------- 64 Bedienungsanleitung --------------------------- User Manual ------------------------------------ 106 Scan for more languages...
- Page 4 Thank you for choosing Aiper. You’ve now joined millions who have already trusted Aiper to care for their pools and are enjoying the convenience of a pristinely clean pool. This user manual will help you maintain your device and ensure it performs at its maximum efficiency for years to come.
-
Page 5: Important Safety Instructions
Robotic Pool Cleaner (hereinafter referred to as device ). Failure to comply may result in electric shock, fire, or serious injury. Aiper is not liable for any losses or injuries caused by improper use of this device. For your safety and the optimal performance of this device, please read and follow these instructions: 1. - Page 6 39. The device is not protected against the effect of freezing. It shall not be left outside during freezing weather conditions. 40. CAUTION: • FOR USE WITH SWIMMING POOLS ONLY. • FOR USE ONLY WITH AUTHORIZED AIPER WIRELESS CHARGER DOCK, MODEL: CHW1. SAVE THESE INSTRUCTIONS...
-
Page 7: Product Components
Product Components 2.1 Package Contents Robotic Pool Cleaner * 1 Charging Dock * 1 Charger * 1 Replaceable MicroMesh™ Ultra-fine Filter * 1 Hook * 1 User Manual * 1 2.2 Component Overview Robotic Pool Cleaner (Side View) : Power Button Roller Brush Caterpillar Tread Top Shell... - Page 8 Filter Box Handle Notes: • A replaceable MicroMesh™ ultra-fine filter is included with the purchase of this device. For filtering finer debris like sand, dirt, and certain types of algae, it is recommended to use this Filter filter instead of the standard one for improved performance.
-
Page 9: Operating Conditions
• NaCl: Maximum 5000 ppm 3.2 Downloading the App Download the Aiper App to unlock more features for your device: You can download and install the Aiper App by scanning the QR code below or by searching for Aiper in your App store. Notes: •... - Page 10 3.4 Charging CAUTION: Please fully charge the device before using it to clean the pool. Do not charge the device in direct sunlight. It's advised that a minimum distance of 3.5m (11.5 ft) separates your pool and charging location. For the best results, your charging location should have Wi-Fi coverage, as this will expedite OTA updates.
-
Page 11: Cleaning Process
Hero Mode, Floor Mode, Floor + Wall Mode, and Skimming Mode. Additional modes are available in the Aiper App. Before submerging the device into the water, place the device on a horizontal surface for 5 seconds. - Page 12 4. The details of each cleaning mode are described below: • Hero Mode: The device will clean the pool floor, pool walls, and water surface sequentially. While cleaning the walls, it will clean the waterline at the same time. Hero Mode •...
- Page 13 • Skimming Mode: The device will clean the pool’s water surface for 3 hours. Skimming Mode Note: The device's cleaning route may be updated with firmware versions. For the most accurate information, please refer to the device's actual performance or the latest official guidance. Cleaning Intensity Selection ECO: Energy-saving mode.
-
Page 14: Maintenance
If, for any reason, the device doesn’t ascend to the water’s surface, attach the included hook to any standard telescopic pool pole (not included) to extend the reach. Hook and lift the device out of the pool. 6. Allow the device to drain any stored water before storing or charging the device. - Page 15 3. Press the latch on the bottom of the filter box 4. Empty, rinse and dry the filter box. and lift the top handle to open it. 5. For a thorough cleaning of the filter box, press the latch to remove the filter for cleaning. 6.
- Page 16 Notes: • After each cleaning task, promptly remove the device from the pool and clean the filter box immediately. Avoid leaving the device in the pool for extended periods. • Drying the filter and filter box after each cleaning is not required and is recommended solely to prevent moisture-related odors.
- Page 17 4.3 Cleaning Impeller / 1. Remove the filter box, and unscrew each of the 4 screws on the both sides of the filter box with a Water Surface Cleaning screwdriver. Impeller 2. Pull the impeller upwards and remove it. While holding the impeller, unscrew the screws on the end. 3.
- Page 18 4. Reinstall the end cap and the gear in order, and secure all removed screws with a screwdriver. CAUTION: The on the impeller and the on the end cap should be aligned with each other. 5. Insert the impeller into the filter box. Ensure that the on the end cap and the on the filter box are aligned with each other.
- Page 19 3. Remove the rear wheel and caterpillar tread of 4. Align the gears of the replacement caterpillar the device by gently pulling each piece. tread with the gears on both wheels. Reinstall the rear wheel and the caterpillar tread, ensuring that they are secured along the tread sleeves.
-
Page 20: Specifications
4.6 Powering Off and Storing Your Aiper During off-seasons, such as winter or long vacations, when your Aiper device isn’t in use, follow these steps to keep it in top shape: 1. Fully charge the device before storing it. Ensure the device is turned off and disconnected from the charger before storing. -
Page 21: Led Indicator
LED Indicator Indicator Types Indicator Status Status Description Pulsing Blue Remote Control Mode. Pulsing Green Charging. Solid Green Charging Complete. To Reset the Device: Hold for 5 seconds. The device will then be restored to its factory settings. Pulsing Yellow OTA in Progress: The device is automatically updating to the latest firmware. -
Page 22: Troubleshooting
Only operate the device in an environment between high/low. 10°C (50°F) and 40°C (104°F). Follow the Powering Off and Storing Your Aiper section Extended non-use of the in the Maintenance guide for proper storage of the device has caused the device. -
Page 23: Warranty
4. The order number or record of purchase must be presented at the request of any repair claim during the warranty period. 5. This is an additional warranty offered by AIPER INTELLIGENT SARL, 43-47 avenue de la Grande Armée, 75116 Paris, France. This warranty does not affect the free of charge remedies for lack of conformity that the consumer holds against the seller, according to law. - Page 24 Please, dispose of batteries and accumulators correctly at your local community waste collection/recycling center. Manufacturer Shenzhen Aiper Intelligent Co., Ltd. Units 3201, 3203A and 3205, 32nd Floor, Block C, Phase 2 Galaxy World, Minle Community, Minzhi Street, Longhua District, Shenzhen, Guangdong, China, 518129 CN Tel: +86075521018957 Email: service@aiper.com http://www.aiper.com...
- Page 27 www.aiper.com...
