- Page 1 ROBOTIC POOL CLEANER User Manual Seagull 3000...
- Page 3 Thank you for choosing Aiper robotic pool cleaner. You have joined millions of people to enjoy the convenience of robotic pool cleaning. This user manual helps you to keep your robot performing at its best. Please take a few moments to read through it.
-
Page 4: Table Of Contents
CONTENTS Important Precautions ----------------------------- 1. Introduction ------------------------------------- 2. Structure ---------------------------------------- 3. Specifications ----------------------------------- 4. Operations --------------------------------------- Important Notes --------------------------------- 4.1 Operation Panel Instructions --------------- 4.2 Panel Light Indicators ----------------------- 4.3 App ------------------------------------------ 4.4 Charging ------------------------------------- 4.5 Filter Cleaning ------------------------------- 4.6 Installation of Foam Floating Blocks -------- 5. -
Page 5: Important Precautions
Important Precautions 1. Read the manual carefully, and use the cleaner according to the manual. We are not liable for any losses or injuries caused by improper use. 2. Only use the accessories recommended or sold by the manufacturer. 3. Do not allow children to ride on the cleaner or play with it. 4. -
Page 6: Introduction
20. Make sure the charging socket is dried before charging. 1. Introduction The robotic pool cleaner Seagull 3000 is a new type of highly efficient and energy-saving swimming pool cleaning robot. It cleans the pool walls and floor automatically without replacing the pool water. It's totally environment-friendly. -
Page 7: Specifications
3. Specifications 1. Model Seagull 3000 2. Rated Working Voltage 25.9V 3. Power 120W 4. Run Time 110~120 Mins 5. Charger Input 100~240V, 50/60Hz 6. Charger Output 30V/2A 7. Battery Capacity 7800mAh 8. Charging Time 4~5 Hours 9. Pool Size Up to 3229sq.ft (300㎡) -
Page 8: Operation Panel Instructions
handle for putting it into the pool, then power on the cleaner (Make sure that the trapped air inside is emptied till no more air bubbles come out before powering on). 2. The cleaner will automatically sub-stop alongside the pool wall once the battery is low or completing a working cycle. -
Page 9: Panel Light Indicators
Item Sign Instruction Description Press ON button, the cleaner Power ON is powered on. Press OFF button, the cleaner Power OFF is powered off. Press this button, the cleaner will start to work automatically according to the selected START Start to Work cleaning mode, and the corresponding mode indicator will start to flash with the... - Page 10 Once floor Flash once “Beep” once wall per second Wall Flash once “Beep” cleaning per second Flash Floor once “Beep” cleaning Auto second Running Flash There times Flash once once floor once “Beep” per second wall second →Flash →Flash Working once once per “Beep”...
-
Page 11: App
Flash fast Abnormal Out of once per Indications water 0.1s 4.3 App DOWNLOAD THE APP : Please search “AIPER” on App Store or Google Play to download the App. 12： 00 12： 00 12： 00 Connected Connected Connected Manual Mode... -
Page 12: Charging
Notes: 1.If the Bluetooth is disconnected, please do the Bluetooth pairing again by hand; 2.During App operation, if you need to change the cleaning mode, please pause the current working status first and select the new mode, then start it. Otherwise, the cleaning mode won’t change; 3.During App operation, if the Bluetooth is disconnected, the cleaner will follow the last cleaning direction till low battery warning. -
Page 13: Filter Cleaning
Charger Indicators Red light stays on: the battery is being charged. Green light stays on: 1. The charger is not plugged to the cleaner; 2. The charging is completed. 4.5 Filter Cleaning A. Slide the two clips according to the indications on the top cover to open it and take out the filters. -
Page 14: Installation Of Foam Floating Blocks
C. Re-install the filters, pay attention to the right position and slide the two clips to close the top cover. 4.6 Installation of Foam Floating Blocks Attention: If your robot is performing well, please ignore these instructions. The following illustration is limited to the use of white foam blocks to increase coverage when the cleaning machine cannot completely clean and cover the pool area and climb walls well. -
Page 15: Frequently Asked Questions (Faq)
Floating Block Installed Internally Floating Block Installed Internally 5. Trouble Shooting Remark: The pool water condition must be within the following parameters: • PH: 7.0 —7.4 • Temperature: 10°C(50°F) to 35°C(95°F) • Salt: Max 5,000 ppm • Chlorine: Max 2 ppm Issues Possible Causes Solutions... - Page 16 The filter baskets need Clean and wash the to be cleaned filter baskets The robot The PVC rollers are worn Replace new rollers does not or consumed too much climb walls The pool wall radian is too It doesn’t work for too big or the surface is too curved or slippy walls.
-
Page 17: Packing List
6. Packing List Item Description Name Model (pc) Cleaner Seagull 3000 Charger Cordless Robotic User Manual Pool Cleaner Floating Battery with 9.84ft(3m) Cable Floating Blocks... -
Page 18: Warranty
7. Warranty This product has passed all quality control and safety tests, conducted by the technical department of the factory. Warranty Information 1. The warranty is covered for 24 months (only for battery and motor) from the date of its original purchase. 2. - Page 20 Aiper Customer Service: US Toll Free: 1-866-850-0666 Email: service@aiper.com Facebook: @AiperOfficial...
