- Page 1 ROBOTIC POOL CLEANER User Manual Orca 800 Mate...
- Page 3 Thank you for choosing Aiper robotic pool cleaner. You have joined millions of people to enjoy the convenience of robotic pool cleaning. This user manual helps you to keep your robot performing at its best. Please take a few moments to read through it.
-
Page 4: Table Of Contents
CONTENTS Important Precautions ----------------------------- 1. Introduction ------------------------------------- ---------------------------------------- 2. Structure 3. Specifications ----------------------------------- 4. Operations -------------------------------------- Attentions ------------------------------------------ 4.1 Control Panel and Indicator Instructions ------ 4.2 Functions & Adjustments of Nozzles ---------- 4.3 Filter Cleaning ---------------------------------- 5. Trouble Shooting -------------------------------- 6. -
Page 5: Important Precautions
Important Precautions 1. Read the manual carefully, and use the cleaner according to the manual. We are not liable for any losses or injuries caused by improper use. 2. To avoid any accidents/damages, please fix the power supply unit 11.5ft (3.5m) away from the swimming pool by using the included safety rope, in case it falls into the water and result in potential danger. -
Page 6: Introduction
20. Do not allow children to ride on the cleaner or play with it. 1. Introduction The robotic pool cleaner Orca 800 Mate is a new type of highly efficient and energy-saving swimming pool cleaning robot. Through its advanced computer-controlled program, it cleans the pool floor (even with an max slope 30°)automatically. -
Page 7: Specifications
3. Specifications 1. Model Orca 800 Mate 2. Rated Input Voltage 110V~120V, 60Hz 3. Rated Working Voltage DC 17V 4. Power 150W 5. Optional Working Cycles 1H/2H/3H 6. Pool Size Up to 33ft(10m) 79GPM (300LPM) 7. Filter Capacity 180μm 8. Filter Density 9. - Page 8 2. When pulling the cleaner out of the water, suspend the cleaner on the water for about 10-15 seconds to empty the water inside. Please hold the top handle only; never pull the cable. 3. Please install the swing plate and brush before use for normal working. 4.
-
Page 9: Control Panel And Indicator Instructions
4.1 Control Panel and Indicator Instructions Sign Instruction Function description Press this button, the cleaner is power-on. ON/OFF Power on/off Press a second time, the cleaner is off. The cleaner runs for 1 hour CYCLE The cleaner runs for 2 hours The cleaner runs for 3 hours Indicates the working cycle and fault warning 1H, 2H and 3H... -
Page 10: Functions & Adjustments Of Nozzles
4.2 Functions & Adjustments of Nozzles There are two nozzles on the cleaner, one of them opens when the other closes. Water flows out through the open nozzle to thrust the cleaner to move forward. Adjust the nozzle by turning it to control the moving route. a. -
Page 11: Filter Cleaning
Setting Three: 20°--20°, for round pools Nozzle Angle Moving Route Note: These are recommended settings and different settings might apply to specific pools. So the operator can adjust the settings according to the principle of nozzle settings and the actual situation of the pool. 4.3 Filter Cleaning A. -
Page 12: Trouble Shooting
B. Take out the filter tray C. Wash the filter tray and chassis D. Reassemble the cleaner and clip on 5. Trouble Shooting Remark: The pool water condition must be within the following parameters: • PH: 7.0 —7.4 • Salt: Max 5,000 ppm •... - Page 13 Place the power supply The power supply unit unit at a proper position is improperly positioned to reach all pool areas There is algae on the Before using the cleaner, pool floor and it can’t please clean the algae on be cleaned since it the floor or walls in case The robot...
-
Page 14: Packing List
User Manual Safety Rope 7. Warranty 1.This product is covered by Aiper warranty for 24 months ( only for driving kit and control box kit) from the date of purchase. Consum- able parts are beyond warranty which include Filter Tray/Brush/ Wheels/Nozzles. - Page 16 Aiper Customer Service: US Toll Free: 1-866-850-0666 Email: service@aiper.com Facebook: @AiperOfficial...
