Printronix P7000 Quick Setup Manual page 38

Set The Top-Of-Form
Figure 28. Aligning the First Print Line with the TOF Indicator
3. Locate the TOF indicator. It is a small tab located on both the
right and left tractor doors.
4. Turn the vertical position knob to align the top of the first print
line with the TOF indicator. For best print quality, it is
recommended that the top-of-form be set at least one print line
or more below the perforation.
NOTE: For exact positioning, press the VIEW/EJECT key to move
38
TOF Indicator
the last data printed to the tractor area for viewing. While in
View mode "Printer in View" displays. Press the Up or
Down Arrow keys to move the paper vertically in small
increments. Pressing the VIEW/EJECT key a second time
moves the paper back to the adjusted print position. The
key works both online and offline provided that the printer is
in View mode. (This procedure is applicable for both the
cabinet and pedestal models.)
Perforation
Vertical
Position
Knob
