Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
WARNING:
AVERTISSEMENT : Risque potentiel de blessure grave ou de mort.
CAUTION:
ATTENTION : Risque de blessure mineure.
ATTENTION:
• Risk of property damage.
•
Risque de dommages matériels.
NOTE:
A note draws attention to important information.
TIP: A tip provides a suggestion to make working with the application easier.

Software Commands

Commands are written in the fonts shown here:
^AR Merge Scene,,0p1 scene 1,1 ^B 51 ^W^C.0
[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]
E X! *X1&*
NOTE:
character "0" is the number zero and "O" is the capital letter "o."
Computer responses and directory paths that do not have variables are written in the font shown here:
Reply from 208.132.180.48: bytes=32 times=2ms TTL=32
C:\Program Files\Extron
Variables are written in italics as shown here:
ping xxx.xxx.xxx.xxx —t
SOH R Data STX Command ETB ETX
Selectable items, such as menu names, menu options, buttons, tabs, and field names are written in the font
shown here:
From the
File
Click the
OK

Specifications Availability

Product specifications are available on the Extron website, www.extron.com.

Extron Glossary of Terms

A glossary of terms is available at https://www.extron.com/technology/glossary.aspx.
Potential risk of severe injury or death.
Risk of minor personal injury.
X2)* X2#* X2! CE}
For commands and examples of computer or device responses used in this guide, the
menu, select .
New
button.
