Ultimaker S5
Repair manual: Print head cable
Required
Tools
• ESD prevention supplies
• Safety plug
• Torque screwdriver (adjustable)
• 0.15 Nm
• 0.5 Nm
• Safety Torx TX10 bit
• 2.0 mm hex bit
• 2.0 mm hex screwdriver
• Flat sided screwdriver (recommended)
• Door fixation tools
Parts
• 1x 1384 - Print head cable
Time
• 20 minutes
Notes
Caution:
Make sure the Ultimaker S5 is turned off and the
power cable is disconnected before you start the replacement.
Safety note:
The Ultimaker S5 a built-in power supply that is
exposed when the bottom cover is removed. Insert the safety
plug before removing the cover. Never connect the power cable
when the bottom cover is removed.
Caution:
This repair involves working with or exposing
sensitive electronic components. Take ESD precautions before
starting this procedure.
Tip:
All orientations are as seen from the front in the upright
orientation, unless specified otherwise.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ultimaker S5
Summary of Contents for Ultimaker S5
- Page 1 Repair manual: Print head cable Required Notes Tools Caution: Make sure the Ultimaker S5 is turned off and the • ESD prevention supplies power cable is disconnected before you start the replacement. • Safety plug • Torque screwdriver (adjustable) • 0.15 Nm...
- Page 2 Pull the part upwards in a straight line; it should detach Tip: Use a tool such as a (flat-sided) screwdriver to firmly, but without too much resistance carefully, press the clip against the connector Tools: Flat-sided screwdriver (recommended) Ultimaker S5 Repair manual: Print head cable...
- Page 3 11. Move the cover away from the printer and 12. Press the clip of the print head cable and pull the disconnect the speaker cable cable out of the connector on the mainboard Note: The bottom cover can be placed aside Ultimaker S5 Repair manual: Print head cable...
- Page 4 Push all other wires to the side and fold the connector to the easily fits through it side. This makes it easier to move the cable through the small hole in the bottom panel Ultimaker S5 Repair manual: Print head cable...
- Page 5 Tip: Reach in through the top of the Ultimaker S5, or carefully Tip: Make sure the connector clicks into place. Gently pull the cable open the glass doors...
- Page 6 Reassembly 7. Place the Ultimaker S5 upright again 8. Insert the print head cable into the print head with the clip on the connector towards the back Tip: Use the door fixation tools to prevent the doors from Tip: Make sure the connector clicks into place. Gently pull the cable...
