Rear Bumper
Please verify all parts are present and read instructions carefully before starting installation.
Please feel free to contact your distributor if you have any kind of question about your purchase.
CONTENTS
1
Left
C1
H1
B: Main Body
Qty
Part Name
18
Hex Bolt
18
Split Lock Washer
TOOLS REQUIRED
2
Drive Ratchet Handle
19mm, 22mm Shallow Socket
C1&C2: Wings
Size(mm)
M12*30
D12
19mm, 22mm Wrench
If want to the view electronic pdf, please
scan the QR code.
MAKE A DIFFERENCE
B
H1&H2: Mounting Brackets
Qty
Part Name
28
Flat Washer
10
Hex Nut
To view online instruction, please
BXG.9108-S
(INSTALLATION INSTRUCTION)
Right
C2
H2
Size(mm)
M12*30*2
M12
scan the QR code.
