Front Bumper
CONTENTS
1
TOOLS REQUIRED
2
Drive Socket Ratchet Wrench
4mm Hex Bit Socke
19mm Wrench
10mm, 19mm Shallow Socket
MAKE A DIFFERENCE
INSTALLATION TIME
3
About 1 hour, 1-2 people may be needed.
Installation time may differ according to
your mechanical skill level.
(PLEASE VERIFY ALL PARTS ARE PRES-
ENT AND READ INSTRUCTIONS CAREFUL-
LY BEFORE STARTING INSTALLATION!)
To view the electronic version (BXG.9082),
please scan the QR code.
(INSTALLATION INSTRUCTION)
Bolts
Qty
Part Name
Hex Bolts
6
12
Split Lock Washer
12
Flat Washer
6
Hex Nuts
Button Head Socket
4
Cap Bolts Screws
4
Flat Washer
2
Nylon Round Spacer
4
Nylon Insert Lock nut
2
EVA
BXG.9082
Size(mm)
M12*30
D12
M12*30*2
M12
M6*20
M6*12*1
M6*12*1.3
M6
Advertisement
Related Manuals for HOOKE ROAD BXG.9082
Summary of Contents for HOOKE ROAD BXG.9082
- Page 1 4mm Hex Bit Socke your mechanical skill level. 19mm Wrench (PLEASE VERIFY ALL PARTS ARE PRES- 10mm, 19mm Shallow Socket ENT AND READ INSTRUCTIONS CAREFUL- LY BEFORE STARTING INSTALLATION!) To view the electronic version (BXG.9082), please scan the QR code.
- Page 2 INSTALLATION INSTRUCTION Step 4 Install the mounting bracket onto the main body using M12 washers, flat washers, and Step 1 nuts. Remove the factory part shown in the picture. Step 5 If you need to use a license plate, assemble the license plate bracket as shown in the picture below and mount it onto the main body.
- Page 3 Step 6 Install the bumper into your vehicle with the factory bolts. Step 7 The installation is complete. We hope you enjoy a wonderful off-road life with this quality Hooke Road product! The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product.
