- Page 1 Gas Spring TV Wall Mount Instruction Manual SKU: MOUNT-VW03G Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vw03g help@vivo-us.com www.vivo-us.com 1-800-371-5654...
- Page 2 CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us. com, email at help@vivo-us.com, or call us at 1-800-371-5654.
- Page 3 STEP 2 (Continued) STEP 4 OPTION B: Concrete/Brick Wall Secure VESA adapters (D, E) to VESA plate using bolts (C) in the appropriate configuration to match Use mount (A) to mark mounting holes on wall. Using a 3/8” drill bit, drill holes at least 2.4” deep into your televisions mounting holes.
- Page 4 STEP 5 Adjust as Desired To adjust gas spring lift strength, turn the screw on the top of the center joint using the large Allen Attach VESA plate assembly to back of monitor using bolts (M-C, M-D, M-E) and washers (M-G). wrench (G).
- Page 5 Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
