Monitor and Laptop Desk Stand
Instruction Manual
SKU: STAND-V002FGL
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v002fgl
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V002FGL
Summary of Contents for Vivo STAND-V002FGL
- Page 1 Monitor and Laptop Desk Stand Instruction Manual SKU: STAND-V002FGL Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v002fgl GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Assemble Pole Base (J) to Pole (A) using M6x16mm Screws (S-D) and 4mm Allen Wrench (T-A). Insert Grommet Plate (I) into Pole Base (J). STEP 2 Remove adhesive backing from Soft Pad (G) and stick it to the top of Base Plate (H) making sure the holes in both line up. - Page 4 STEP 4 Remove adhesive backing from Pads (P) and stick them to Foot Pads (M). STEP 5 Slide Monitor Arm (D) over Pole (A). Secure Monitor Arm (D) at the desired height using 6mm Allen Wrench (T-C).
- Page 5 STEP 6 Slide Laptop Arm (C) over Pole (A). Secure Laptop Arm (C) at the desired height using 6mm Allen Wrench (T-C). Insert Pole Cap (L) into the top of Pole (A). STEP 7 Attach Arm Cable Clips (N) to Laptop Arm (C) and Monitor Arm (D), and Pole Cable Clip (O) to Pole (A).
- Page 6 STEP 8 Secure VESA Plate (E) to the back of the monitor using M4x12mm Thumbscrews (M-A), or M4x30mm Screws (M-B) and M4 Spacers (M-C). STEP 9 Assemble VESA Plate (E) to Laptop Tray (F) using M4x8mm Screws (S-A) and M4 Nuts (S-B). Tighten using Wrench (T-D) and a Phillips screwdriver.
- Page 7 STEP 10 Slide the monitor with VESA Plate (E) onto Monitor Arm (D), and VESA Plate (E) with Laptop Tray (F) onto Laptop Arm (C). Secure VESA Plates (E) with M6 Nuts (S-C). STEP 11 Place your laptop on Laptop Tray (F). Adjust tilt using 5mm Allen Wrench (T-B). STEP 12 CAUTION: To prevent tipping, please be careful not to extend the arms too far forward or backward.
