Dual Vertical Monitor Desk Stand with Glass Base
Instruction Manual
SKU: STAND-V002LG
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v002lg
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V002LG
Summary of Contents for Vivo STAND-V002LG
- Page 1 Dual Vertical Monitor Desk Stand with Glass Base Instruction Manual SKU: STAND-V002LG Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v002lg GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Tools Needed
TOOLS NEEDED 22 lbs DO NOT EXCEED WEIGHT CAPACITY. Per Arm (10 kg) Failure to do so may result in serious injury. Phillips Screwdriver ASSEMBLY STEPS STEP 1 Remove protective film from Foam Pad (G) and apply the Support Plate (H). Attach Support Plate (H) to Lower Pole (D) using M6x16mm Screws (S-B) and 4mm Allen Wrench (T-A). - Page 4 STEP 3 Remove protective film from Feet (J) and apply to the bottom of Base (C). Remove protective film from Felt Pads (K) and apply them to the bottom of Feet (J). STEP 4 Slide Plastic Cover (I), Pole Cable Clip (L), and Tilt Joint (B) onto Lower Pole (D). Use 6mm Allen Wrench (T-B) to lock the position of Tilt Joint (B).
- Page 5 STEP 5 Press Pole Cap (F) into Upper Pole (E) on the side without internal threading. Thread Upper Pole (E) onto Lower Pole (D). STEP 6 Slide Pole Cable Clip (L) and Tilt Joint (B) onto Lower Pole (D). Use 6mm Allen Wrench (T-B) to lock the position of Tilt Joint (B).
- Page 6 STEP 7 OPTION A: Flat Back Monitor Attach VESA Plate (A) to the monitors with Screws (M-A,M-C) and M5 Washers (M-E). OPTION B: Curved Back Monitor Attach VESA Plate (A) to the monitors with Screws (M-B,M-D), M5 Washers (M-E), and Spacers (M-F).
- Page 7 STEP 9 Adjust the tilt in Tilt Joints (B) using 6mm Allen Wrench (T-B). STEP 10 Route cables through Cable Clips (L). Adjust monitors as desired and Store Allen Wrenches (T-A,T-B) in Cable Clips (L).
