Pneumatic Arm Dual Monitor Desk Mount
Instruction Manual
SKU: STAND-V002O
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v002o
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-V002O
Summary of Contents for Vivo STAND-V002O
- Page 1 Pneumatic Arm Dual Monitor Desk Mount Instruction Manual SKU: STAND-V002O Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v002o GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Remove gas spring arm (A) from packaging. While holding arm closed, cut the shipping tie and gently release arm. STEP 2 OPTION A: Clamp Installation Mount bracket (B) to bottom of gas spring arms (A) using M6x12 bolts (D). Tighten using 4mm Allen wrench (J). - Page 4 STEP 2 (Continued) OPTION B: Grommet Base Installation For grommet hole mounting, place carriage bolt (G) through the center of grommet base (F). Mount grommet base to bottom of gas spring arms (A) using M6x12 bolts (D). Tighten using 4mm Allen wrench (J).
- Page 5 STEP 4 Adjust tension in gas spring arms (A) using 5mm Allen wrench (K). Turning clockwise decreases strength, and counter-clockwise increases.
- Page 6 STEP 5 Remove bottom plastic covers from gas spring arms (A) using Phillips screwdriver end of 5mm Allen wrench (K). Run cables from monitors through bottom of gas spring arms (A), then reattach plastic covers.
- Page 7 STEP 6 Adjust monitor tilt support using 5mm Allen wrench (K) as shown. Adjust monitor position as desired.
- Page 8 - 92% within < 3hr www.vivo-us.com AVG. RESOLUTION TIME : < 15 M (within office hrs) Chat live with an agent! 309-278-5303 AVG. RESOLUTION TIME : 5M 4S (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
