Rotenso CONTROL Series User Manual page 36

RSC wired central controller
EN
7.6 How to set the function and relevant parameters of the weekly timer of the air conditioner?
1. Press to enter the setting status interface of single air conditioner. Press the button repeatedly to select „Single" and „All"
alternately, display „Set". If you select Single, press
2. Selecting „All" indicates to set the weekly timer parameters of all air conditioners, and „All" is displayed. Selecting „Single" displays
the address of the air conditioner; for example, if the air conditioner whose address is 12 is selected, „12" is displayed.
3. Press to select the day of the week.
4. Set the parameter of period 1, including shutdown time, startup time, running mode, Fan speed and temperature. First of all, set
the startup and shutdown time. Press
startup and shutdown time.
5. Press to select running mode: automatic, cool, heat, Fan-only, Dry, or Off. If you select the cool, automatic or heat mode,
press to adjust the temperature (the scope is within 17 - 30 degree). Press to regulate Fan speed, which can be
selected among automatic speed, low Speed, middle speed and high speed.
6. Finish the weekly timer parameter setting of the air conditioner within period 1 of the day of the week.
7. Continually set periods 2, 3, 4 according to the above operation.
8. After finishing the setting of the periods, continually select the day of the week needed to be set, to set the weekly timer
parameter from Monday to Sunday, seven days in total.
36
User manual
Under the main interface
Press to select air conditioner
to the next step.
Press to select the day of the
week to the next step.
to select the startup time and shutdown time. Press
Press to save the parameter of
the period 1 to the next step.
Press to save the parameter of
the period 1 to the next step.
to select one.
Press to cancel the selection
and return to the last step.
Press to cancel the selection
and return to the last step.
Press to cancel the set of
period 1 and return to the last step.
Press to cancel the set of
period 1 and return to the last step.
Finish setting
to modify the
