Rotenso CONTROL Series User Manual page 32

RSC wired central controller
EN
6.2 Key instructions of the weekly-timer central controller
Key name
6.3 The main interface of the weekly-timer central controller (user interface)
• Under the other pages, press
• Under the other pages, automatically return to the main interface when no operation for a period
time.
• The main interface displays the on-line condition of the indoor unit.
Sixty-one indoor units
are online
Date
32
User manual
The central controller re-scans the indoor unit in the network as recharging
Under the main page, press the "Program" button to set the weekly timer of single
indoor unit or all indoor units. Press the "Query" button and hold, and then press the
"Program" button to query the weekly timer parameters of the indoor unit.
Under the main page, press the „Weekly" button to start up or shut down the weekly
Under the main page, press the „Time" button for 5 seconds to enter the time-modify-
ing status, and then press „Add" or „Reduce" button to modify the time. Press „Left" or
„Right" to select minute/ hour/ day/ month/ year. Finally, press the „Confirm" button
Save data and send the command required to the indoor unit, such as setting the
Cancel the last operation and return to the last interface.
to return to the main interface.
Usage
after power off.
timer function.
to save the modification
mode of the air conditioner.
of
The online condition of
the indoor unit
