6.2 Key instructions of the weekly-timer central controller
Key name
Press the ON/OFF button. All air conditioners will be shut down if they are running,
on the contrary, they will be started up. If you press the button for less than
5 seconds, the startup mode is the last running mode of the air conditioner.
If you press the button for more than 5 seconds, the startup mode is cooling,
Press the „SET" button, and then select „set single" or „set all". „Set single" indicates to
set the parameter (such as mode/ temperature/ Fan speed/ weekly timer) of
an selected air conditioner. „Set all" indicates to set the parameter of all air
conditioners controlled by the central controller.
Press the „Query" button to query the running condition of the air conditioner, such
as on/off, temperature setting, indoor temperature, running mode and Fan speed.
Press „up", „down", „left" and „right" to select the air conditioner that you
When querying or setting the indoor unit, press „up" to select the indoor unit to be
When querying or setting the indoor unit, press „down" to select the indoor unit to
When querying or setting the indoor unit, press „Left" to select the indoor unit to be
set or queried. In setting the weekly timer, it is used for selecting the day of the week
and the timer of startup and shutdown.
When querying or setting the indoor unit, press „Right" to select the indoor unit to
be set or queried. In setting the weekly timer, it is used for selecting the day of the
week and the timer of startup and shutdown.
When querying the indoor unit, press the „Add" button to query more parameter of
the indoor unit. In setting the indoor unit, it is for modifying the setting temperature.
In setting the weekly timer, it is for modifying the time of startup and shutdown.
When querying the indoor unit, press the „Reduce" button to query more
parameter of the indoor unit. In setting the indoor unit, it is for modifying the
setting temperature. In setting the weekly timer, it is for modifying the time of
Error In setting the indoor unit, it is used for setting the running mode of the indoor
unit which includes Automation,Cool, Heat, Fan Only, Dry and Off.
In setting the indoor unit, it is for setting the wind speed of the indoor unit which
includes high speed, middle speed, low speed and automatic speed.
In setting the indoor unit, it is for setting the swing-function of the indoor unit.
The running mode is selected between „swing-on" and „swing-off".
When setting, press the „Lock" button to lock the remote controller of all or single in-
door unit. Press the „Query" button and hold under the main page, then repress the
„Lock" button again to lock the keyboard of the central controller; press the „Mode"
button and then repress the „Lock" button to lock the running mode.
Usage
high speed, 24 degrees.
want to query.
set or queried.
be set or query.
startup and shutdown.
You can select among them.
You can select one among them.
