INSTALLATION MANUAL
PRODUCT:
MODEL:
PART NO:
PART NO:
CAUTION!
To reduce the risk of serious injury or damage, please read and understand all instructions and
procedures before attempting to install or use this product. Safety glasses must be worn at all
times during installation or maintenance of this product. Ensure all mounting bolts are tensioned
after 250 miles (400 km) and periodically there after.
NOTICE
Whilst the bumper adds additional protection to your vehicle, precautionary measures still need to
be taken to avoid damage. Always drive to the conditions and your surroundings.
Ver. 2
REAR BUMPER
JEEP WRANGLER JL (2018-)
2D.2709.2-NL STUBBY
2D.2723.2-NL FULL WIDTH
www.rival4x4.com
www.rival4x4.com
Advertisement
Related Manuals for Rival 2D.2709.2-NL
Summary of Contents for Rival 2D.2709.2-NL
- Page 1 MODEL: JEEP WRANGLER JL (2018-) PART NO: PART NO: 2D.2709.2-NL STUBBY 2D.2723.2-NL FULL WIDTH CAUTION! To reduce the risk of serious injury or damage, please read and understand all instructions and procedures before attempting to install or use this product. Safety glasses must be worn at all times during installation or maintenance of this product.
- Page 2 * The Bumper must be mounted and affixed to the vehicle according to the installation manual provided by an authorized Rival dealer or Motor dealer or by a special vehicle repairer or fitment center. * Estimated time for installation: 2 hours.
-
Page 3: Parts Listing
PARTS LISTING Rear stubby bumper 2D.2709.2-NL 1. Aluminum bumper body ....Qty 1 2. Licence plate bracket ....... Qty 1 3. Right bracket........Qty 1 4. Left bracket ........Qty 1 5. Tow bar square......... Qty 1 6. Tow hook........... - Page 4 3. Right bracket........Qty 1 4. Left bracket ........Qty 1 5. Tow bar square......... Qty 1 6. Tow hook.......... Qty 2 7. Rear bumper wire extension.... Qty 1 Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com Date: 01-Feb-2022 < Page 4 of 16 >...
- Page 5 U. Spacer plate 2mm......Qty 4 V. Spacer plate........Qty 6 W. Parking sensor holding bracket..Qty 4 X. Spacer plate 2mm......Qty 6 Y. Insert bracket М12......Qty 1 Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com Date: 01-Feb-2022 < Page 5 of 16 >...
- Page 6 6. Unscrew 2 bumper's fitting nuts on the left and right side of the vehicle (Fig.5). and right side, close to body mount kit rear. Uninstall OE bumper (Fig.6). Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com Date: 01-Feb-2022 < Page 6 of 16 >...
- Page 7 12. Fix left bracket (pos.4) using bolts M14 and M10 (Fig.11). M14x35 (pos. H) and washers 14 (pos.L) Tighten hardware after that. (Fig.12). Tighten hardware after that. Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com Date: 01-Feb-2022 < Page 7 of 16 >...
- Page 8 Usually you'll need 3 spacers on yeach side of the vehicle. Fig.17 Fig.18 17. Measure the distance between the outer edges of the tow hooks. The distance should be 29.84-30inch (758-762mm) (Fig.17 and Fig.18). Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com www.rival4x4.com www.rival4x4.com Date: 01-Feb-2022...
- Page 9 22. Connect wiring of the license plate screws M6x20 (pos.B), washers 6 (pos.I) and bracket lights through the license plate hole nuts M6 (pos.P) (Fig.23). Tighten hardware (Fig.24). after that. Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com www.rival4x4.com www.rival4x4.com Date: 01-Feb-2022 < Page 9 of 16 >...
- Page 10 26. Unscrew 3 screws and carefully snap off bracket on the left and right side (Fig.27). 3 plugs that hold outer sidewall bumper bracket on the left and right side (Fig.28). Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com Date: 28-Jan-2022 Date: 01-Feb-2022...
- Page 11 (Fig.32). Fig.33 Fig.34 31. Disconnect parking sensors wiring from 32. Take parking sensors off the bumper plastic bumper reinforcement (Fig.33). (Fig.34). Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com Date: 01-Feb-2022 < Page 11 of 16 >...
- Page 12 (pos.7) (Fig.38). А1. Wire..........Qty 1 A2. Heat-shrink tubing...... Qty 4 A3. Corrugation......... Qty 1 A4. Female terminal......Qty 4 A5. Make terminal......Qty 4 Fig.38 Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com Date: 01-Feb-2022 < Page 12 of 16 >...
- Page 13 Fig.43 Fig.44 40. Place the heat-shrink tubing (pos. A2) 41. Place the corrugation (pos. A3) over the over the terminals, then heat the tubing entire extension. (Fig.44). (Fig.43). Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com Date: 01-Feb-2022 < Page13 of 16 >...
- Page 14 М10х30 (pos.C) and countersunk (pos. U) and spacer plate (pos.V), both sides, washers (pos.N) (Fig.47). Tighten hardware fix it using OE bolts M10 (Fig.48). Tighten after that. hardware after that. Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com Date: 01-Feb-2022 < Page 14 of 16 >...
- Page 15 INSTALLATION PROCEDURE Before operating a vehicle fitted with a RIVAL Bumper 2D.2709.2-NL: - make sure all fittings are tightened - check all electrical wiring attached to lights Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com Date: 01-Feb-2022 < Page 15 of 16 >...
- Page 16 INSTALLATION PROCEDURE Before operating a vehicle fitted with a RIVAL Bumper 2D.2723.2-NL: - make sure all fittings are tightened - check all electrical wiring attached to lights Thank you for your choice! Sincerely, RIVAL 4x4 Team Installation manual 2D.2709.2-NL, 2D.2723.2-NL www.rival4x4.com...
