INSTALLATION MANUAL
PRODUCT:
MODEL:
PART NO:
CAUTION!
To reduce the risk of serious injury or damage, please read and understand all instructions and
procedures before attempting to install or use this product.
Safety glasses must be worn at all times during installation or maintenance of this product.
Ensure all mounting bolts are tensioned after 600 miles (1000 kms) and periodically there after.
Do not use damaged product or hardware.
Ver. 3
REAR ALUMINUM FENDER FLARES
JEEP WRANGLER JL (2018 - ON)
2D.2731.1
www.rival4x4.com
www.rival4x4.com
Advertisement
Related Manuals for Rival 2D.2731.1
Summary of Contents for Rival 2D.2731.1
- Page 1 REAR ALUMINUM FENDER FLARES MODEL: JEEP WRANGLER JL (2018 - ON) PART NO: 2D.2731.1 CAUTION! To reduce the risk of serious injury or damage, please read and understand all instructions and procedures before attempting to install or use this product.
- Page 2 JEEP WRANGLER JL (2018 - ON) SAFETY NOTICE * The RIVAL Fender Flares are designed to complement the use and design of the specified vehicle under conditions specified by the vehicle manufacturer. * While driving the vehicle at any speed, collision with any other vehicle, animal or object must always be avoided.
-
Page 3: Parts Listing
Qty 1 3. Right fender (passenger’s side) ....... Qty 1 4. Right fender bracket (passenger’s side) ....Qty 1 5. Weatherstrip ............Qty 1 PASSENGER’S SIDE DRIVER’S SIDE Installation manual 2D.2731.1 www.rival4x4.com Date: 26-May-2022 < Page 3 of 9 >... - Page 4 А. Screw М6х20......... Qty 24 В. Penny washer 6......Qty 32 С. Nut М6..........Qty 8 D. Insert nut М6 with cable....Qty 2 E. Cage nut М6........Qty 8 Installation manual 2D.2731.1 www.rival4x4.com < Page 4 of 9 > Date: 26-May-2022...
- Page 5 4. Install insert nut (item. D). 3. Carefully remove OE fender by pulling fender. Fig. 5 5. Cut weatherdtrip (item 5) in the middle, on 2 equal parts. Installation manual 2D.2731.1 www.rival4x4.com Date: 26-May-2022 < Page 5 of 9 >...
- Page 6 6. Stick weatherstrip (item. 5) on face side of fender, on the edge of fender, as shown in g. 6-7. NOTE! Begin by installing RIVAL 2D.2732.1 inner fender liner in case if you plan to install RIVAL 2D.2731.1 Fender Flares with RIVAL 2D.2732.1 inner fender liners.
- Page 7 11. Push fender to the vehicle body, to align the fender with the vehicle. Repeat steps 1 - 12 for the passenger’s side RIVAL 2D.2731.1 Fender Flares installation with OE inner fender liners. Fig. 12 Fig. 13 13. On driver’s side, mark cutting line and drilling points on OE inner fender liners, same as on g.13, matching with fender bracket and body of the vehicle.
- Page 8 21. Install fender (item 1) as shown on steps 6-10. OE hardware as shown in g. 20. Repeat steps 1 - 6, 13 - 21 for the passenger’s side Installation manual 2D.2731.1 www.rival4x4.com < Page 8 of 9 > Date: 26-May-2022...
- Page 9 INSTALLATION PROCEDURE Before operating a vehicle fitted with RIVAL Aluminum Fender Flares 2D.2731.1 make sure all fittings are tightened. Installation manual 2D.2731.1 www.rival4x4.com Date: 26-May-2022 < Page 9 of 9 >...
