Pulse Output - F&F LE-03MW Manual

» Optical communication port in accordance with EN62056
(IEC1107);
» Pulse output SO with programmable number of pulses per
kWh;
» Multifunction LCD display.
Measured values
Consumed and supplied
active energy
Consumed and supplied
reactive energy
Phase voltages
Phase currents
Frequency
Active power
Reactive power
Apparent power
Power factor

Pulse output

The indicator has a SO+/SO- pulse output. This allows you to
connect a pulse meter-reading pulses generated by the counter.
For proper operation of the indicator is not required to connect
additional devices.
AE+/AE-
RE+/RE-
U1, U2, U3 [V]
I1, I2, I3
f
P
Q
S
- 3 -
[kWh]
[kvarh]
[A]
[Hz]
[W]
[var]
[VA]
