Operation and setting
Configuration with the touch panel > 'Weekly program' (weekly schedule)
3.4.4 Operating mode
Personnel:
Facility manager

1. On the touch panel select 'Menu è Unit
components' .
2. Select the fan symbol ①.
3. Set the operating mode ①:
- Auto mode 'Calendar'
AHU operation is based on the calendar;
you can define the calendar mode on the
web server.
- Auto mode 'Weekly program'
AHU operation is based on a 'weekly pro-
gram' (weekly schedule); you can define the
weekly program with the touch panel.
- Service stop
The AHU stops running, but voltage supply
remains on. Use this mode to carry out
service (maintenance).
You can deactivate this mode only on the
touch panel.
- Standby mode
- Manual mode with low fan speed
- Manual mode with high fan speed
30
Note: You can also use the digital control panel or
the web server to select an operating mode. None
of these entry modes has preference; the AHU
runs with the operating mode that was selected
last (except for service stop
Under normal conditions the AHU should run
based on calendar or 'weekly program' (weekly
schedule).
3.4.5 'Weekly program' (weekly schedule)
Personnel:
Facility manager

A 'weekly program' allows you to set the AHU operating
times.
1. Select 'Menu è Weekly program' .
2. You can choose between three 'weekly programs':
① - Whole week: Identical schedule for all days.
② - Daily program: Different schedule for every
③ - Weekday & weekend: Different schedules for
Select a weekly program, then use the switch ④
to activate it. Only one program (schedule) can be
active at a time.
AHU X-CUBE X2 compact 2
day.
working days and weekends.
).
