Muratec MFX-1330 User Manual page 131

Item
"Name"
"Server Name"
"IP Address"
"Port Number"
"Account"
"Password"
"Log-in Required"
"User Log-in"
"Start Point"
Description
Enter the name for identification purposes.
Enter the LDAP server name.
Enter the IP address of the LDAP server.
• IP address is given to priority if both the LDAP
server name and IP address are registered.
Enter the port number that the LDAP server is
using.
The default port number is 389.
Enter the account name used to log-on to the LDAP
server.
Enter the password used to log-on to the LDAP
server.
If the LDAP server requires authentication, select
"Yes".
When it is set to "Yes", the OfficeBridge users will be
prompted to enter an account name and password
when they access the LDAP server for searching a
destination.
NOTE: This account name and password can be
registered on the
advance.
Set the search start position when searching the
LDAP server.
Using the Admin Tools
"User Set-UP" screen, in
1
2
3
4
5
6
7
8
9
10
11
12
13
AI
3-65
