Multi-Tech CallFinder Quick Start
Extension Mic Gain: This value adjusts the volume of
the phone's microphone. Default = 8.
if outgoing audio signal is constant but low.
Decrease value
cuts out or is clipped.
This parameter is sensitive and important to system
performance.
Extension Speaker Gain: This value adjusts the volume
of the phone's speaker. Default = 30.
Increase value
low.
Decrease value
cuts out or is clipped.
This parameter is sensitive and important to system
performance.
c. Click Update.
d. Click on Current Status. Watch the Current Status:
Channel-1/Channel-2 portion of the screen. The "State" of
each channel should be "Waiting for Ring."
e. From an ordinary POTS phone, dial one of the DID phone
numbers that is active in the system. Dial the DID phone
number as you would from an outside line (it will not work to dial
the number as if it were an ordinary 3- or 4-digit extension).
Server Installation
if outgoing audio signal intermittently
if outgoing audio signal is constant but
if outgoing audio signal intermittently
19
Increase value
