- Page 1 ® CallFinder DID-to-Analog Adapter Model CF220-DID Cabling Guide...
- Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc., to notify any person or organization of such revisions or changes. Check Multi-Tech’s web site for current versions of our product documentation.
-
Page 3: Mechanical Mounting
CallFinder Cabling Guide Introduction This guide describes the hardware setup of the CF220-DID CallFinder unit, and some preliminary considerations for its inter- operation with PBX units. Instructions for software setup can be found in the User Guide. Mechanical Mounting The CF220-DID CallFinder can be surface mounted with screws spaced according to the dimensions shown. -
Page 4: You Supply
We Supply • A CallFinder (CF220-DID) with factory-installed software • A two-piece 9 Vdc power supply with power cord • Four common telephone cables (1 for each port; RJ-11 at both ends) • A product CD that contains: (a) a system management software package for the administrator’s PC, and (b) - Page 5 212-555-4100 through 212-555-4109. When ordering your DID line, ask the telco representative for these details about the DID service. These details will be important when setting up your CF220-DID unit. Parameter Number of digits used to designate the DID extension (usually 3, 4, 6, or 7) Type of “DID Start”...
- Page 6 CallFinder Cabling Guide Quick Hookup for CF220-DID CallFinder CF220-DID Hookup Cabling to telco DID lines. Connector at CallFinder: RJ-11. Power Cable Connector at telco end: RJ-11. Reset Receptacle Switch 10/100 CHANNEL 2 CHANNEL 1 RESET FXS/FXO FXS/FXO Cabling to your Ethernet LAN.
-
Page 7: Cabling Instructions
Cabling Instructions Summary : Place the CallFinder in a convenient location, and then connect it to earth ground, to your AC power outlet, to your Ethernet network, and to your telco DID service. You cannot connect the CallFinder's Extension Ports (FXS/FXO) to your PBX until after you have configured the CallFinder software. - Page 8 Connect CallFinder to Power Insert the 9 Vdc power connector into the CallFinder’s power receptacle and fasten it with the lock nut. Connect the female end of the AC cord to the power block. Then plug the AC cord into the power outlet. Caution: Use only the 9 Vdc power transformer supplied with the CallFinder.
- Page 9 Verify powering. After power is applied, the PWR LED comes on immediately but there is a 4-second delay before the Status LED comes on. In normal operation, the Status LED will be flashing. When you apply power, the CallFinder performs a diagnostic self-test.
- Page 10 If it is a 192.168.2.x subnet, it may clash with the CallFinder because the CallFinder’s default IP address is 192.168.2.1. To remedy such a situation, connect directly from the Admin PC to the CallFinder using an RJ45 cable until the CallFinder’s IP address has been configured.
- Page 11 Identify CallFinder’s Extension Ports (FXS/FXO) for Later Hookup Caution: You must wait until after the CallFinder software has been configured before connecting the cables between the CallFinder’s Extension (FXS/FXO) Ports and the PBX. Because the CallFinder and the PBX can both supply battery power, the cable connections must be done properly.
- Page 12 Patents This device is covered by one or more of the following patents: 6,031,867; 6,012,113; 6,009,082; 5,905,794; 5,864,560; 5,815,567; 5,815,503; 5,812,534; 5,809,068; 5,790,532; 5,764,628; 5,764,627; 5,754,589; D394,250; 5,724,356; 5,673,268; 5,673,257; 5,644,594; 5,628,030; 5,619,508; 5,617,423; 5,600,649; 5,592,586; 5,577,041; 5,574,725; D374,222; 5,559,793; 5,546,448; 5,546,395; 5,535,204;...
