Server Installation

2. Logging In (I)

a. Bring up a Web browser on your pc. At the browser's address
line, type the CallFinder's default IP address: http://192.168.2.1
and press Enter.
b. The Login screen will appear.
At this point you can be assured that the CallFinder is
connected to the network.
If the Login screen does not appear, see item #1, "What if I
can't see the web page for my CallFinder?" in the
Troubleshooting section (page 23).
c. At the Login screen, enter admin (all lower case) in the User
Name field.
d. Enter admin (all lower case) in the Password field.
e. Click the Login button. The CallFinder software Home screen
will appear. From this screen, you can access all of the
CallFinder software screens.

3. Setting CallFinder IP Addresses

a. In the CallFinder Administration screen, go to the IP
Configuration fields.
Administration: IP Configuration
192.168.4.89
IP Address
255.255.255.0
Subnet Mask
192.168.11.251
Name Server
update
b. Fill in the IP information that applies to your CF220 CallFinder
Server unit. The fields for "IP Address," "Subnet Mask," "Default
Gateway" and "Name Server" are required. A "Secondary
Name Server" may be considered optional.
c. Click Update. The CallFinder will adopt the new IP address 5
seconds after the Update command is invoked.
Multi-Tech CallFinder Quick Start
Default Gateway 192.168.4.1
Secondary
Name Server
