Server Installation
: This refers to DID battery polarity. This
Polarity
parameter must be set (and possibly reset, as
needed) on a trial-and-error basis.
Signs of incorrect polarity:
(1) outside party originating call to DID number gets
immediate busy signal after dialing;
(2) line suddenly disconnects just when call should
go through.
PBX Extension Line Parameters
Extension Port: default = FXO (prevents damage from
Set as FXO when
a PBX station port (a port that is normally connected
to a normal analog telephone).
Set as FXS when
a PBX trunk port (a port that would normally be
connected to an ordinary POTS phone line from the
telco central office.
Auto Attendant Delay: The Auto Attendant Delay value,
x, determines how long the CallFinder will pause
before dialing on the PBX.
If the CallFinder channel is configured as an FXS port
will ring the PBX and wait x seconds before dialing
the proper extension after the PBX seizes the line.
Set x to be 1 or greater.
If the CallFinder channel is configured as an FXO port
x is the length of time that the CallFinder will wait
before dialing after the CallFinder itself has seized
the line from the PBX.
Set x to 0. This requires the CallFinder to detect dial
tone from the PBX before dialing.
Multi-Tech CallFinder Quick Start
wrongly applied battery
and ring voltages)
the CallFinder is to be connected to
the CallFinder is to be connected to
18
it
,
