Sonesse 30 WF Li-ion RTS
Note: Ensure the motor has been fully charged and the RTS receiver has been
activated prior to installation.
To check the motor charge status, connect to the charger. The Charger LED will
illuminate the following:
Solid Red - Charging
Solid Orange - Charging near completion
Solid Green - Charging is complete
1. WAKE THE MOTOR UP
When using a multi-channel RTS control, remember to select the desired channel
prior to programming
Hold the UP & DOWN buttons on the remote together until the motor jogs up &
down
•
If the motor doesn't jog, move to step 2
•
If the motor jogs, move to step 3
Programming the Motor

Advertisement

loading
Need help?

Need help?

Do you have a question about the SONESSE 30 WF Li-ion RTS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SOMFY SONESSE 30 WF Li-ion RTS

Summary of Contents for SOMFY SONESSE 30 WF Li-ion RTS

  • Page 1 Sonesse 30 WF Li-ion RTS Programming the Motor Note: Ensure the motor has been fully charged and the RTS receiver has been activated prior to installation. To check the motor charge status, connect to the charger. The Charger LED will...
  • Page 2 2. RESET MOTOR There are two possible ways to reset the motor which will depend on the motor the customer has: 1. Motor Option 1: 2 x cables protruding from motor head - Press & hold the program button on the motor head until you get 3 jogs 2.
  • Page 3 5. SET TOP LIMIT Using the UP button, move the blind to the top limit. Once at the top limit, briefly press the MY & DOWN button until the blind moves to the bottom limit 6. SET BOTTOM LIMIT Press MY button to stop the motor at your desired bottom limit. Once at the preferred bottom limit, briefly press the MY &...
  • Page 4 7. SAVING THE PROGRAMMING TO THE RTS REMOTE Flip the remote control over. Using a screw, pen or anything small enough, press the program button on the back of the remote control for less that 0.5 of a second; similar to a quick prick The motor will jog to confirm the motor limits have been saved NOTE: Do not press and hold the program button on the remote.
  • Page 5 FLOWCHART FOR PROGRAMMING THE MOTOR...
