  • Page 1 SONESSE 30 WF LI- ON Instructions Instrucciones Notice инструкции...

  • Page 2: Table Of Contents

    SONESSE 30 WF RTS LI-ION ORIGINAL INSTRUCTIONS These instructions apply to all SONESSE 30 WF RTS LI-ION drive, the different versions of which are available in the current catalogue. CONTENTS 1. Prior information 3. Operation and maintenance 1. 1. Sphere of application 3.

  • Page 3: Installation

    SONESSE 30 WF RTS LI-ION 2. INSTALLATION These instructions are mandatory for the home motorisation and automation professional installing the drive. Never drop, knock or puncture the drive or immerse it in liquid. Install an individual control point for each drive.

  • Page 4: Wiring

    To ensure electrical safety, this Class III motor must be powered by a «SELV» voltage source (Safety Extra Low Voltage). Use power charger (recommended by Somfy) to charge the drive battery. Ensure battery is fully charged prior to installation. 1) Connect the charger to the cable attached to drive.
  • Page 5 This function is used to deactivate the radio transmission to save the battery life during shipment, or when the product will not be used for an extended amount of time (ex: storage). 1) To deactivate the “RTS” Radio Technology Somfy, press the UP, MY and DOWN buttons simultaneously, until the driven product briefly moves Up and Down...

  • Page 6: Tips And Advice On Installation

    SONESSE 30 WF RTS LI-ION 2. 4. TIPS AND ADVICE ON INSTALLATION 2. 4. 1. Questions about the drive? Observations Possible causes Solutions The driven product does Drive battery is low and requires Charge the battery. not operate. charge. The control point battery is low.
  • Page 7 SONESSE 30 WF RTS LI-ION Readjusting the lower end limit 1) Briefly press the DOWN button to move the driven product to the lower end limit. 2) Press and hold the UP and DOWN buttons simultaneously until the driven product briefly moves Up and Down.
  • Page 8 SONESSE 30 WF RTS LI-ION 2. 4. 5. Erasing control points (transmitters) from memory To delete all the programmed transmitters, press and hold the motor head programming button until the driven product briefly moves Up and Down twice. All programmed control points (transmitters) are deleted.

  • Page 9: Operation And Maintenance

    3. 1. MODE SELECTION: ROLLER OR TILTING MODE The SONESSE 30 WF RTS LI-ION is designed to work in 2 modes: Tilting mode or Roller mode. This feature allows the SONESSE 30 WF RTS LI-ION to be set according to the type of application.

  • Page 10: Adjusting The Tilting Speed

    SONESSE 30 WF RTS LI-ION 3. 4. ADJUSTING THE TILTING SPEED 1) To decrease the tilting speed, press and hold the MY and DOWN buttons simultaneously until the driven product briefly moves Up and Down. Repeat as needed. The minimum speed has been reached when the driven product no longer moves Up and Down.

  • Page 11: Adjusting The Speed

    SONESSE 30 WF RTS LI-ION 3. 6. ADJUSTING THE SPEED LED blinks alternately in green and Yellow. 1) Move the driven product away from the end limits. Press and hold the UP, MY and DOWN buttons simultaneously, until the driven product briefly moves Up and Down once.

  • Page 12: Technical Data

    For additional information on the technical data for this drive contact your Somfy representative. SOMFY ACTIVITES SA, F-74300 CLUSES as manufacturer hereby declares that the drive covered by these instructions and used as intended according to these instructions is in compliance with the essential requirements of the applicable European Directives and in particular of the Machinery Directive 2006/42/EC, and the Radio Directive 2014/53/EU.
